| Ref | Part Number | Description |
|---|
| 1 |
94-3004 |
SHAFT-DRIVE, SPLINED Price: $564.48 |
| 2 |
136-2366 |
BACKPLATE ASM Price: $957.74 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
136-2365 |
HOUSING ASM Price: $971.03 |
| 4 |
76-6910 |
ROTATING KIT Price: $2,143.15 |
| 5 |
76-6970 |
INSERT-PLATE, CAM Price: $140.84 |
| 6 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 7 |
94-3002 |
SCREW-CAP Price: $7.19 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 9 |
60-6240 |
WASHER Price: $15.20 |
| 10 |
106-6876 |
SEAL KIT Price: $48.83 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 12 |
532402463 |
PULLEY.ASM.ENGINE.1-1/8X3-1/4 Price: $54.99 |
| 13 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 14 |
76-6980 |
O-RING Price: $11.28 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
94-3003 |
PLATE-VALVE Price: $515.64 |
| 16 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 95 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 105 |
532410616 |
SHIELD SIDE Price: $4.99 |
| 106 |
532410617 |
SHIELD SIDE Price: $5.99 |
| 107 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 108 |
532410532 |
NEEDS DESCRIPTION Price: Call Us |
