| Ref | Part Number | Description |
|---|
| 1 |
115-8293-0P |
TUBE-SHORT This part replaces 115-8293-03. Price: $224.35 |
| 1 |
532146323 |
Drive Control (AYP part number) Price: $34.99 |
| 2 |
114-5410 |
SHAFT-SHORT, REAR ROLLER Price: $128.74 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $3.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532700875 |
Carriage Bolt 1/4-20 x 2 (AYP part number) Price: $2.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
532077400 |
Hubcap (AYP part number) Price: $3.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $2.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 8 |
532750851 |
Wheel & Tire Assembly (AYP part number) Price: $3.33 |
| 9 |
812000058 |
E-ring (AYP part number) Price: $1.99 |
| 10 |
532137054 |
Pinion Price: $2.99 |
| 11 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532088080. Price: $2.99 |
| 12 |
532701037 |
SELECTOR KNOB This part replaces 532132800. Price: $2.99 |
| 13 |
532152015 |
Wheel Adjuster Assembly (Left) (AYP part number) Price: Call Us |
| 14 |
532152016 |
Wheel Adjuster Assembly (Right) (AYP part number) Price: Call Us |
| 16 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 18 |
532137090 |
Spring (AYP part number) Price: $3.99 |
| 20 |
532075192 |
Spring Price: $3.99 |
| 21 |
532067725 |
Washer 1/2 x 1-1/2 x .134 (AYP part number) Price: $3.99 |
| 22 |
532702510 |
Gear Case Assembly (AYP part number) Price: $114.14 |
| 23 |
532137052 |
Drive Pulley (AYP part number) Price: $6.99 |
| 24 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $2.99 |
| 27 |
532137080 |
Drive Cover Price: $3.33 |
| 28 |
532146072 |
Pan Head Tapping Screw #10-24 x 2-3/4 (AYP part number) Price: $4.99 |
| 29 |
532149746 |
Pan Head Tapping Screw #10-24 x 1-3/4 (AYP part number) Price: $3.99 |
| 32 |
532157769 |
KIT.SERVICE.BELT/SPRING. This part replaces 532137078. Price: $11.99 |
| 38 |
532086012 |
Drive Shaft Cover (AYP part number) Price: $5.46 |
| 39 |
532088446 |
Wheel Bushing (AYP part number) Price: $2.16 |
| 532146598 |
Drive |
Cover Decal Price: $3.33 532146598 |
