| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
574615401 |
CUTTER DECK w/DECALS Price: Call Us |
| 2 |
32128-21 |
NUT-HF Price: $0.39 |
| 2 |
966956201 |
KIT, HSG ASM 72 This part replaces 539131385. Price: $528.99 |
| 3 |
522023901 |
PULLEY - 7.50 Price: $59.99 |
| 3 |
92-7472 |
REAR TUBE ASM Price: $185.79 |
| 4 |
539101733 |
BLADE OEM 21" (61" DECK) Price: $18.99 |
| 4 |
92-7473 |
REAR TUBE ASM Price: $239.26 |
| 5 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 5 |
76-8350 |
STOP-AXLE Price: $10.92 |
| 6 |
539132583 |
HINGE CHUTE - BLACK Price: $30.99 |
| 6 |
93-7247 |
WASHER-THRUST Price: $3.46 |
| 7 |
237-58 |
O-RING Price: $2.18 |
| 7 |
539130903 |
CHUTE, RUBBER DISCHARGE WB Price: $49.99 |
| 8 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 8 |
539130922 |
BRKT, REINF-CHUTE WB Price: $34.99 |
| 9 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 9 |
92-7536 |
HOSE-HYD Price: $196.76 |
| 10 |
105-9818 |
HOSE-HYD This part replaces 92-7537. Price: $287.57 |
| 10 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 11 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 11 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 12 |
3256-29 |
WASHER-FLAT Price: $2.59 |
| 12 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 13 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 13 |
94-8000 |
NUT-HEX Price: $2.65 |
| 14 |
32151-96 |
RING-RETAINING Price: $0.54 |
| 14 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 15 |
510022302 |
Screws This part replaces 510022301. Price: $5.99 |
| 15 |
71-4580 |
BEARING Price: $80.51 |
| 16 |
539107476 |
BOLT 3/8-16 X 1.0 Price: $5.99 |
| 16 |
71-4590 |
WASHER-THRUST Price: $3.32 |
| 17 |
237-166 |
O-RING Price: $10.46 |
| 17 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 18 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 18 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 19 |
237-81 |
O-RING Price: $2.76 |
| 19 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 20 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 20 |
92-7386 |
HYD MOTOR ASM Price: $2,754.42 |
| 21 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 21 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 22 |
325-4 |
SCREW-HH Price: $0.95 |
| 22 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 23 |
539130690 |
SPRING Price: $9.99 |
| 23 |
94-2825 |
GEAR - DRIVER, 12 PITCH This part replaces 92-7587. Price: $132.80 |
| 24 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 24 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 25 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 25 |
94-2826 |
GEAR - DRIVEN, 12 PITCH This part replaces 92-7586. Price: $160.09 |
| 26 |
340-70 |
NUT-LOCK Price: $2.10 |
| 26 |
522811401 |
BELT, B, 165 Price: $89.99 |
| 27 |
505339602 |
SUPPORT - FRONT, RH ORANGE Price: $29.99 |
| 27 |
92-7553 |
TUBE-REAR DRAIN Price: $174.40 |
| 28 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 28 |
92-7495 |
STEERING TUBE ASM Price: $148.27 |
| 29 |
525854001 |
PIN, HOC Price: $55.99 |
| 29 |
92-7494 |
REAR STEARING TUBE ASM Price: $150.03 |
| 30 |
574169601 |
ROLLER, GAUGE .635 BORN Price: $14.99 |
| 30 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 31 |
574196402 |
Tubes This part replaces 574196401. Price: $5.99 |
| 31 |
92-7534 |
HOSE-HYD Price: $123.48 |
| 32 |
539113739 |
ROD END - 3/8-24 RH Price: $12.99 |
| 32 |
98-7825 |
DISCONTINUED ,ORDER PIECE PARTS This part replaces 93-7780. Price: Call Us |
| 33 |
525854101 |
ROD, HOC Price: $19.99 |
| 33 |
86-5910 |
TIRE-6 PLY Price: $114.98 |
| 34 |
120-8909 |
RIM This part replaces 217-125. Price: $198.53 |
| 34 |
525853902 |
SUPPORT, CASTER 61 OR Price: $249.99 |
| 35 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 35 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 36 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 36 |
74-5500 |
BOLT-WHEEL Price: $10.84 |
| 37 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 37 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 38 |
237-42 |
O-RING Price: $2.78 |
| 38 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 39 |
353-508 |
PLUG-HH Price: $7.96 |
| 39 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 40 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 40 |
92-7539 |
HOSE-HYD Price: $134.23 |
| 41 |
539105461 |
CENTER BAFFLE - 61 Price: $79.99 |
| 41 |
92-7538 |
HOSE ASM Price: $167.59 |
| 42 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 42 |
523024902 |
BAFFLE WLDMT 61 BLK Price: $119.99 |
| 43 |
32151-104 |
RING-RETAINING, EXTERNAL Price: $4.85 |
| 43 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 44 |
121-3653 |
CYLINDER-HYD This part replaces 94-8141. Price: $725.74 |
| 44 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 45 |
525818602 |
COVER.61".RH.GREY Price: $95.99 |
| 45 |
92-5839 |
JOINT-BALL Price: $207.89 |
| 46 |
525818502 |
COVER.61".LH.GREY Price: $95.99 |
| 46 |
92-5833 |
SPACER-JOINT, BALL Price: $20.71 |
| 47 |
525833002 |
HOOK OR Price: $31.99 |
| 47 |
92-5844 |
DISCONTINUED Price: Call Us |
| 48 |
32136-14 |
NUT-HST Price: $3.38 |
| 48 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 49 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 49 |
539132687 |
SPRING - COMPRESSION Price: $4.99 |
| 50 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 50 |
92-5836 |
WASHER Price: $5.34 |
| 51 |
237-78 |
O-RING Price: $3.85 |
| 51 |
539109333 |
WASHER 3/4 FLAT SAE ZD Price: $3.99 |
| 52 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 52 |
539113987 |
SPACER Price: $27.99 |
| 53 |
525305801 |
HAIRPIN Price: $3.99 |
| 53 |
92-7604 |
DISCONTINUED Price: Call Us |
| 54 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 54 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 55 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 55 |
94-8115 |
DISCONTINUED Price: Call Us |
| 56 |
325-33 |
SCREW-HH Price: $11.49 |
| 56 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 57 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 57 |
92-7646 |
ELBOW-BULKHEAD, 45 DEG Price: $105.61 |
| 58 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 58 |
69-8910 |
WASHER Price: $1.70 |
| 59 |
539114823 |
CAP, VINYL Price: $2.99 |
| 59 |
69-8900 |
SPACER Price: $14.26 |
| 60 |
596581701 |
Washers This part replaces 539115528. Price: $2.99 |
| 60 |
92-7552-03 |
DISCONTINUED This part replaces 92-7552. Price: Call Us |
| 61 |
240-7 |
GROMMET-RUBBER Price: $16.51 |
| 61 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 62 |
106-6774 |
JOINT-BALL This part replaces 92-5838. Price: $79.04 |
| 62 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 63 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 63 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 64 |
237-22 |
O-RING Price: $2.43 |
| 64 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 65 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 65 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 66 |
88-1550 |
STOP - 4WD AXLE Price: $47.56 |
| 67 |
94-2806 |
ADAPTOR-STUD, WHEEL Price: $57.68 |
| 68 |
100-3895-03 |
WEIGHT-WHEEL This part replaces 94-3052. Price: $841.13 |
| 69 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 70 |
3213-14 |
SCREW-HH Price: $8.01 |
