| Ref | Part Number | Description |
|---|
| 1 |
50522006 |
WASP GRWLK FRAME W/DECALS Price: Call Us |
| 2 |
06200313 |
BLT, RHSN .38-16X1.00 G5 ZCC This part replaces 00963020. Price: $2.45 |
| 3 |
05517900 |
BSHG-FLG 1.010X1.38X1.4X1.65 Price: $5.45 |
| 4 |
D33002 |
SWIVEL, 3/8-24 Price: $9.45 |
| 5 |
06700223 |
PIN, HAIR #225 .072X1.09 This part replaces 06714800. Price: $0.45 |
| 6 |
05901702 |
BLT,HEX .38-16X.75 G5 ZCC This part replaces 00960045. Price: $1.45 |
| 7 |
00960602 |
WASHER, .375 MED SPRG LOCK Y Price: Call Us |
| 8 |
00964501 |
WASHER, .406X.813X.065 FLAT Y Price: Call Us |
| 9 |
00960046 |
BOLT, 3/8-16X1.00 HEX 5 Y Price: Call Us |
| 10 |
06433600 |
WSHR-FL-NY .375X.75X.060 Price: $0.45 |
| 11 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06545500. Price: $1.45 |
| 12 |
00960052 |
BOLT, 3/8-16X2.50 HEX 5 Y Price: Call Us |
| 13 |
08553700 |
BSHG-SLV .391X.688X.52 PM Price: $5.45 |
| 14 |
03371700 |
ROD, STEERING Price: $14.95 |
| 15 |
08338800 |
SG-COMP .045X.600X.750 WLD7.5 Price: $6.45 |
| 17 |
04950461 |
WASP SHIFT LEVER DETENT Price: Call Us |
| 18 |
04928800 |
GRIP, HANDLEBAR Price: $8.95 |
| 19 |
07533300 |
CAPLUG, HANDLEBAR Price: $2.45 |
| 20 |
78806400 |
KIT, OPC UPDATE This part replaces 04924200. Price: $183.95 |
| 21 |
00964013 |
LOCKNUT, 10-24 NYLOC Y Price: Call Us |
| 22 |
00967054 |
NUT, 3/8-24 STD HEX Y Price: Call Us |
| 23 |
06944700 |
CABLE, CHOKE Price: $52.95 |
| 24 |
05901837 |
BLT, HWH #10-24X.75 ZCC This part replaces 06116900. Price: $1.95 |
| 25 |
06949100 |
CABLE - THROTTLE W/LINER Price: $72.95 |
| 26 |
04940800 |
SWITCH - PTO - NMIR Price: $26.95 |
| 27 |
07517700 |
CAP - IGNITION SWITCH Price: $3.45 |
| 28 |
06517400 |
NUT- PANEL .562-24 GRECO Price: $18.95 |
| 29 |
00539300 |
PLUG, HOUR METER Price: $8.95 |
| 30 |
04928700 |
GRIP, THUMB LATCH Price: $3.45 |
| 31 |
04922600 |
LATCH, LH THUMB Price: $13.45 |
| 32 |
08339300 |
SG-TENS .041X.500X1.750 Price: $5.45 |
| 33 |
04905200 |
LEVER, HAND CONTROL LH Price: $71.45 |
| 35 |
78806400 |
KIT, OPC UPDATE This part replaces 04924100. Price: $183.95 |
| 37 |
78806400 |
KIT, OPC UPDATE This part replaces 04924000. Price: $183.95 |
| 38 |
03602300 |
KEY SWITCH Price: $23.45 |
| 39 |
50522007 |
WASP GRWLK HNDLBAR W/DECALS Price: Call Us |
| 40 |
00181251 |
CAP, FUEL S/O Price: $21.45 |
| 41 |
04943561 |
TANK, FUEL W/MOLDED EVR DECAL Price: Call Us |
| 42 |
03875300 |
ASSY-PICKUP, FUEL This part replaces 09112300. Price: $13.45 |
| 43 |
03278800 |
CLAMP, FUEL LINE This part replaces 00130924. Price: $0.95 |
| 44 |
00192126 |
HOSE, FUEL 1/4 X 30.00 Price: $14.25 |
