| Ref | Part Number | Description |
|---|
| 1 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 2 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 3 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 5 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 6 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 7 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 8 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 9 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 10 |
131-6557 |
ALTERNATOR ASM Price: $443.05 |
| 10 |
539104605 |
BELTSHIELD Price: $27.01 |
| 11 |
539102892 |
DECAL, NO STEP Price: $0.64 |
| 12 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 13 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 14 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 15 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 16 |
539103256 |
SPRING Price: $9.99 |
| 17 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 18 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 19 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 20 |
539100141 |
HCS 7/16F X 1 1/2 Price: $7.99 |
| 20 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 22 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 23 |
539101995 |
KEY 1/4 SQ X 1 1/8 Price: $2.99 |
| 24 |
539103283 |
PULLEY Price: $59.99 |
| 25 |
539102675 |
MACHINERY BUSHING 10 GA. Price: $8.99 |
| 26 |
539102244 |
BUSHING.MACHINE.18.GAUGE Price: $4.99 |
| 27 |
539115279 |
BEARING-ECC LOCK W/COLLAR This part replaces 539102677. Price: $30.99 |
| 28 |
539104852 |
HOUSING, DIE CAST Price: $64.99 |
| 29 |
539102676 |
SPACER Price: $8.99 |
| 30 |
539103290 |
SPINDLE SHAFT Price: $64.99 |
| 30 |
98-7708 |
NUT Price: $7.76 |
| 31 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 32 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 33 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 34 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 35 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 36 |
539104546 |
DEFLECTOR CHUTE Price: $139.99 |
| 37 |
539104197 |
STRUT MOUNT WELDMENT Price: $51.99 |
| 38 |
539104199 |
HCS 5/8C X 2 GR.5 Price: $2.99 |
| 39 |
539102698 |
BUSHING Price: $29.99 |
| 40 |
539102643 |
ANTI-SCALP ROLLER Price: $8.99 |
| 40 |
98-7709 |
COLLAR Price: $8.79 |
| 41 |
539102754 |
HCS 3/8C X 3 1/2 Price: $3.99 |
| 42 |
539105779 |
DECK W/DECALS 48" This part replaces 539104610. Price: $2,799.99 |
| 45 |
539108350 |
STRUT, RIGHT This part replaces 539104609. Price: $549.99 |
| 47 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 48 |
539100344 |
DECAL, DANGER Price: $2.42 |
| 49 |
539111949 |
BELT, DECK 48" This part replaces 539103239. Price: $84.99 |
| 50 |
107-0136 |
ROTOR ASM Price: $268.62 |
| 50 |
539107410 |
HOUSING KIT FOR 103298 This part replaces 539103298. Price: $449.99 |
| 51 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 52 |
539102619 |
PIVOT PIN Price: $32.99 |
| 53 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 55 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 60 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 70 |
107-0138 |
BEARING-BALL Price: $48.37 |
| 80 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 90 |
107-0139 |
DRIVE END FRAME ASM Price: $446.71 |
| 100 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 110 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 120 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 130 |
133-2811 |
BEARING Price: $46.67 |
| 140 |
107-9087 |
FRAME-END Price: $183.56 |
| 150 |
107-0140 |
COVER-END Price: $34.95 |
| 160 |
98-7721 |
RECTIFIER ASM This part replaces 127-1612. Price: $486.45 |
| 170 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 180 |
107-0141 |
BRUSH HOLDER ASM Price: $107.10 |
| 190 |
98-7724 |
BRUSH Price: $12.41 |
| 200 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 230 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 240 |
98-7729 |
BOLT Price: $2.35 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7731 |
BOLT Price: $3.94 |
| 270 |
98-7732 |
NUT Price: $1.45 |
| 539104621 |
539108351 |
STRUT, LEFT This part replaces 539104621. Price: $139.99 |
