| Ref | Part Number | Description |
|---|
| 1 |
33942 |
Cylinder Assy. (Incl. #2, 3, 4 90) Price: Call Us |
| 2 |
26727 |
Pin-Dowel Price: Call Us |
| 3 |
27642 |
Plug-Drain, Oil (SQH 1/4-18) Price: Call Us |
| 4 |
29183 |
OIL SEAL Price: Call Us |
| 5 |
31444A |
Valve, Intake (Std.) (Incl. Nos. 7, 8 9) Price: Call Us |
| 6 |
31445A |
Valve, Exhaust (Std.) (Incl. Nos. 7,8 9) Price: Call Us |
| 6 |
31483 |
EXHAUST VALVE (1/32" OVERSIZE) Price: Call Us |
| 7 |
31671 |
Cap-Upper Valve Spring Price: Call Us |
| 8 |
31672 |
Spring-Valve Price: Call Us |
| 9 |
31673 |
Cap-Valve, Spring Price: Call Us |
| 11 |
93-0688 |
DECAL-WARNING, CHEMICAL This part replaces 31274. Price: $20.09 |
| 12 |
29783 |
Pin, Groove Price: Call Us |
| 13 |
27613 |
Gear, Crankshaft Price: Call Us |
| 14 |
31761 |
Piston Pin Assy. (Incl. 2 of #16) (Std.) Price: Call Us |
| 14 |
32662 |
Piston Pin Assy. (Incl. 2 of #16) (.010 Oversize) Price: Call Us |
| 14 |
32663 |
Piston Pin Assy. (Incl. 2 of #16) (.020 Oversize) Price: Call Us |
| 15 |
27565 |
Ring Set, Piston (Std.) Price: Call Us |
| 15 |
27566 |
Ring Set, Piston (.010 o.s.) Price: Call Us |
| 15 |
27567 |
Ring Set, Piston (.020 o.s.) Price: Call Us |
| 16 |
20381 |
Ring-Retaining, Piston Pin Price: Call Us |
| 17 |
30963B |
Rod Assy., Connecting (Incl. Nos.18, 19 20) Price: Call Us |
| 18 |
26706 |
Bolt, Connecting Price: Call Us |
| 20 |
27573 |
LOCKNUT Price: Call Us |
| 21 |
33149 |
Camshaft (Compression Release Price: Call Us |
| 22 |
27241 |
Lifter-Valve Price: Call Us |
| 23 |
30756B |
Cover, Cylinder (Incl. No. 24, 25, 106 133) Price: Call Us |
| 24 |
28540 |
OIL SEAL Price: Call Us |
| 25 |
27625 |
Plug-Fill, Oil Price: Call Us |
| 26 |
27677 |
Gasket-Cylinder Cover Price: Call Us |
| 27 |
650664 |
Screw (1/4-20 x 1-19/32) Price: Call Us |
| 28 |
30564 |
Screw Price: Call Us |
| 31 |
650489 |
Screw Price: Call Us |
| 32 |
29953B |
Gasket-Cylinder Head Price: Call Us |
| 33 |
30579 |
CYLINDER HEAD Price: Call Us |
| 34 |
26073 |
Washer Price: Call Us |
| 35 |
650694 |
Screw Hex Hd. Cap Price: Call Us |
| 36 |
6021 |
Screw Price: Call Us |
| 37 |
33636 |
Plug, Spark (J17LM or equiv.) Price: Call Us |
| 38 |
27234 |
Gasket-Breather Price: Call Us |
| 39 |
27666 |
Body-Breather Price: Call Us |
| 40 |
27233 |
Element, Breather Price: Call Us |
| 41 |
27667 |
Gasket-Gear Case Price: Call Us |
| 42 |
30322 |
Nut-Lock Price: Call Us |
| 43 |
650128 |
Screw Price: Call Us |
| 44 |
32447 |
Breather Tube Price: Call Us |
| 45 |
26754 |
Gasket-Intake Price: Call Us |
| 46 |
28416 |
Pipe, Intake Price: Call Us |
| 48 |
30646 |
Screw Price: Call Us |
| 51 |
27272 |
Gasket Price: Call Us |
| 52 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 53 |
590416 |
Starter Cup Price: Call Us |
| 54 |
590417 |
Screen, Air Price: Call Us |
| 55 |
31345 |
IDENTIFICATION PLATE Price: Call Us |
| 56 |
28539 |
Ring, Retainer Price: Call Us |
| 58 |
31858 |
Jet-Main Price: Call Us |
| 59 |
28537 |
Washer, Flat Price: Call Us |
| 60 |
31510 |
Lever-Governor Price: Call Us |
| 61 |
30200 |
Screw (10-24 x 9/16) Price: Call Us |
| 62 |
28277 |
Washer-Flat Price: Call Us |
| 63 |
31334 |
Rod-Governor Price: Call Us |
| 64 |
30658 |
Baffle, Blower Housing (Incl. No. 65) Price: Call Us |
| 65 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 66 |
32078 |
INSTRUCTION DECAL Price: Call Us |
| 67 |
29309 |
DRIVE STUD Price: Call Us |
| 69 |
29212 |
Screw Price: Call Us |
| 70 |
30655A |
Housing, Blower Price: Call Us |
| 71 |
650490 |
Washer Price: Call Us |
| 72 |
650607 |
Hex Nut Price: Call Us |
| 73 |
29716 |
Screw Price: Call Us |
| 74 |
16645 |
Lockwasher Price: Call Us |
| 75 |
30747 |
Clip, Shorting Price: Call Us |
| 76 |
31708 |
BRACKET, AIRCLEANER Price: Call Us |
| 77 |
28820 |
Screw (10-32 x 1/2) Price: Call Us |
| 78 |
31700 |
AIRCLEANER Price: Call Us |
| 79 |
31692 |
Body Price: Call Us |
| 80 |
650152 |
Screw Price: Call Us |
| 81 |
31871 |
DECAL, AIRCLEANER Price: Call Us |
| 82 |
32446 |
GROMMET Price: Call Us |
| 83 |
29633 |
Muffler Price: Call Us |
| 84 |
6202 |
Screw Price: Call Us |
| 85 |
31342 |
Spring-Compression Price: Call Us |
| 86 |
650549 |
Screw Price: Call Us |
| 87 |
26756 |
Gasket Price: Call Us |
| 89 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 90 |
30980 |
BUSHING, CRANKSHAFT Price: Call Us |
| 91 |
33879 |
Control Assy., Speed (Incl. #42, 85, 86 95) Price: Call Us |
| 92 |
28942 |
Screw (10-32 x 3/8) Price: Call Us |
| 93 |
27261 |
Washer Price: Call Us |
| 94 |
33966 |
Bracket-Gov. Speed Limit Price: Call Us |
| 98 |
650695 |
Screw, Hex Hd. Cap Price: Call Us |
| 100 |
26460 |
Clamp-Line, Fuel Price: Call Us |
| 101 |
31335 |
Clamp-Lever, Governor Price: Call Us |
| 102 |
650548 |
Screw Price: Call Us |
| 105 |
28458 |
BALL BEARING Price: Call Us |
| 106 |
30574 |
Shaft-Governor Price: Call Us |
| 107 |
30591 |
Gear Assy., Governor (Incl. No.132) Price: Call Us |
| 108 |
29193 |
Ring-Retaining Price: Call Us |
| 109 |
30588A |
Spool-Governor Price: Call Us |
| 118 |
32342 |
Line, Fuel Price: Call Us |
| 120 |
650128 |
Screw Price: Call Us |
| 121 |
29745 |
Extension-Blower Price: Call Us |
| 122 |
29540 |
Bracket, Fuel tank lower Price: Call Us |
| 123 |
29683 |
Fitting Shut-off, Fuel Price: Call Us |
| 124 |
650116 |
LOCKNUT Price: Call Us |
| 125 |
650168 |
Washer Price: Call Us |
| 126 |
410144B |
Cap, Fuel Price: Call Us |
| 127 |
29809 |
Tank Assy., Fuel (Incl. No. 115) Price: Call Us |
| 128 |
650556 |
Screw Price: Call Us |
| 129 |
27247 |
Key Flywheel Price: Call Us |
| 130 |
31426 |
Spring-Extension Price: Call Us |
| 131 |
29443 |
Clip-Wire Price: Call Us |
| 132 |
30590A |
Washer-Flat Price: Call Us |
| 134 |
29539 |
BRACKEN, FUEL TANK UPPER Price: Call Us |
| 144 |
610690A |
Magneto Price: Call Us |
| 145 |
631070A |
Carburetor Price: Call Us |
| 146 |
590420 |
Starter, Rewind Price: Call Us |
