| Ref | Part Number | Description |
|---|
| 1 |
106-0363 |
COUPLING-FLYWHEEL Price: $575.21 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532188715. Price: $180.99 |
| 2 |
100-4852 |
WASHER-HARDENED Price: $4.63 |
| 2 |
532140551 |
Bracket, Pivot Seat Price: $3.99 |
| 3 |
106-0364 |
PLATE-ADAPTER, PUMP Price: $834.17 |
| 3 |
532140675 |
Strap Asm Fender Price: $3.99 |
| 4 |
98-0655 |
HYD HOSE ASM Price: $149.15 |
| 5 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
532145006 |
Clip, Push In Hinged Price: $2.99 |
| 6 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
353-992 |
FLANGE-SPLIT Price: $20.28 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
340-135 |
O-RING Price: $5.91 |
| 8 |
532171877 |
Bolt 5/16-18 Unc x 3/4 Price: $3.99 |
| 9 |
107-1181-03 |
PUMP-GEAR Price: $3,808.00 |
| 10 |
106-0378 |
SCREW ( .50-20UNFX1.25 GRADE 8) Price: $1.70 |
| 10 |
532195530 |
PAN, SEAT This part replaces 532182493. Price: $14.99 |
| 11 |
354-42 |
FLANGE-SPLIT Price: $14.79 |
| 12 |
532174648 |
Bracket, Mounting Switch Price: $4.99 |
| 12 |
74-2270 |
FITTING-SUCTION Price: $119.55 |
| 13 |
532121248 |
Bushing, Snap Price: $3.99 |
| 13 |
69-5640 |
HOSE-RETURN Price: $36.06 |
| 14 |
325-6 |
SCREW-HH Price: $1.42 |
| 14 |
872050412 |
Bolt, Carriage 1/4-20 x 1-1/2 Price: $3.99 |
| 15 |
532121249 |
Spacer, Split Price: $3.99 |
| 15 |
99-4969 |
TUBE-SUCTION Price: $139.85 |
| 16 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 16 |
532123740 |
Spring, Cprsn Price: $3.99 |
| 17 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 18 |
323-6 |
SCREW-HH Price: $0.66 |
| 19 |
69-9220-03 |
BRACKET-TUBE, SUCTION Price: $23.66 |
| 20 |
107-1413 |
WASHER-HARDENED Price: $1.08 |
| 20 |
532124238 |
Cap Spring Seat Price: $3.99 |
| 21 |
532171852 |
Bolt, Shoulder 5/16-18 Price: $3.99 |
| 22 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 23 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 24 |
532177946 |
Track Slide Seat LH Price: $37.99 |
| 24 |
99-4968 |
TUBE-SUCTION Price: $199.94 |
| 25 |
33115-025 |
SCREW-HH Price: $0.61 |
| 25 |
532177947 |
Track Slide Seat RH Price: $65.99 |
| 26 |
33115-030 |
SCREW-HH Price: $0.68 |
| 26 |
819111012 |
Washer 11/32 x 5/8 x 12 Ga. Price: $3.99 |
| 27 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 28 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 28 |
810010500 |
Washer Split Price: $2.99 |
| 29 |
2412-104 |
CLAMP-R Price: $2.37 |
| 33 |
539976934 |
HCS.5/16-18X3/4 This part replaces 874780512. Price: $1.99 |
| 35 |
532125613 |
CAP This part replaces 532178426. Price: $2.99 |
