| Ref | Part Number | Description |
|---|
| 1 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 1 |
532121749 |
WASHER Price: $1.99 |
| 2 |
3218-13 |
NUT-JAM, BRASS Price: $0.88 |
| 2 |
532150546 |
STEERING WHEEL KIT This part replaces 532126805. Price: $59.99 |
| 3 |
8-8150 |
DISCONTINUED Price: Call Us |
| 3 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 4 |
321-4 |
SCREW-HH Price: $0.99 |
| 4 |
532100712 |
Washer 17/32 x 2-1/4 x .160 (AYP part number) Price: $2.42 |
| 5 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 5 |
532150546 |
STEERING WHEEL KIT This part replaces 532121472. Price: $59.99 |
| 6 |
38-8680 |
DISCONTINUED Price: Call Us |
| 6 |
532100711 |
Adapter Wheel Strg 758/ 753id (AYP part number) Price: $11.99 |
| 7 |
321-2 |
SCREW-HH Price: $2.79 |
| 7 |
810040400 |
LOCKWASHER Price: $3.99 |
| 8 |
3217-5 |
NUT-HEX Price: $0.25 |
| 8 |
532140398 |
Dash Black Yard Pro (AYP part number) This part replaces 532124252. Price: $129.99 |
| 9 |
3217-6 |
NUT-HEX Price: $1.19 |
| 9 |
TBD |
Price: Call Us |
| 10 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 10 |
532109816 |
NYLINER T (7283A) Price: $2.99 |
| 11 |
3-8947 |
DISCONTINUED Price: Call Us |
| 11 |
817490608 |
SCREW LT Price: $3.99 |
| 12 |
353-711 |
CONNECTOR Price: $21.73 |
| 12 |
532121748 |
WASHER Price: $1.99 |
| 13 |
5-4541 |
DISCONTINUED Price: Call Us |
| 13 |
532156544 |
STEERING SHAFT This part replaces 532124043. Price: $64.99 |
| 14 |
3220-7 |
NUT-JAM Price: $4.09 |
| 14 |
874780616 |
BOLT This part replaces 874760614. Price: $3.99 |
| 15 |
3-8928 |
DISCONTINUED Price: Call Us |
| 15 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 16 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 16 |
532124036 |
BRKT,STEERING Price: $4.99 |
| 17 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 17 |
873680600 |
LOCKNUT Price: $1.99 |
| 18 |
324-6 |
SCREW-HH Price: $0.81 |
| 18 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 19 |
5-0786 |
KEY Price: $13.87 |
| 19 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532124033. Price: $27.99 |
| 20 |
3246-4 |
SCREW-SET Price: $0.75 |
| 20 |
812000029 |
RING CLIP Price: $1.99 |
| 21 |
49-8110 |
HANDLE GRIP This part replaces 235-11. Price: $13.80 |
| 21 |
532006266 |
WASHER THRUST Price: $5.99 |
| 22 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 22 |
532136874 |
GEAR.SECTOR Price: $49.99 |
| 23 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 23 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 24 |
5-1671 |
DISCONTINUED Price: Call Us |
| 24 |
532104805 |
Dash Assembly, Lower (AYP part number) Price: $34.49 |
| 25 |
28-2470 |
FOOT PAD Price: Call Us |
| 25 |
874180512 |
SCREW Price: $3.99 |
| 26 |
40-7310 |
DISCONTINUED Price: Call Us |
| 26 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 27 |
3-9351 |
EXT SPRING *R Price: $47.40 |
| 27 |
532138884 |
Price: $20.84 |
| 28 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 28 |
873680600 |
LOCKNUT Price: $1.99 |
| 29 |
3-8997 |
DISCONTINUED Price: Call Us |
| 29 |
874760532 |
BOLT Price: $2.99 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 30 |
532121236 |
Spacer Split 59/ x 1.25 Blk/zin (AYP part number) Price: $2.38 |
| 31 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 31 |
532106965 |
Plate, Support, Battery (AYP part number) Price: $10.37 |
| 32 |
323-7 |
SCREW-HH Price: $0.65 |
| 32 |
874760612 |
BOLT Price: $1.99 |
| 33 |
3218-3 |
NUT-JAM Price: $0.25 |
| 33 |
532057079 |
THRUST WASHER Price: $2.99 |
| 34 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 34 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $6.99 |
| 35 |
40-8090 |
DISCONTINUED Price: Call Us |
| 35 |
819091016 |
WASHER This part replaces 532126684. Price: $2.99 |
| 36 |
5-1853 |
DISCONTINUED Price: Call Us |
| 36 |
532132781 |
Control, Choke (AYP part number) This part replaces 532122926. Price: $19.99 |
| 37 |
5-2933 |
DISCONTINUED Price: Call Us |
| 37 |
810040400 |
LOCKWASHER This part replaces 811050400. Price: $3.99 |
| 38 |
321-6 |
SCREW-HH Price: $0.25 |
| 38 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 39 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 39 |
874780616 |
BOLT This part replaces 874760614. Price: $3.99 |
| 40 |
5-0701 |
ANCHOR Price: $4.07 |
| 40 |
532108075 |
Axle, Assembly, Front (AYP part number) Price: $62.55 |
| 41 |
3-9026 |
DISCONTINUED Price: Call Us |
| 41 |
532105663 |
Support, Saddle, Rear (AYP part number) Price: $8.25 |
| 42 |
3-8945 |
DISCONTINUED Price: Call Us |
| 42 |
874761060 |
BOLT LT Price: $3.99 |
| 43 |
3220-3 |
NUT-HJ Price: $0.28 |
| 43 |
532105664 |
SUP-SADDLE FRT LT Price: $9.99 |
| 44 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 44 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 45 |
282-1 |
DISCONTINUED Price: Call Us |
| 45 |
532110438 |
Spacer, Bearing, Axle, Front (AYP part number) Price: $5.99 |
| 46 |
5-3840 |
DISCONTINUED Price: Call Us |
| 46 |
583612401 |
LOCKNUT M (1 2) (5 2) This part replaces 873601000. Price: $2.99 |
| 47 |
323-9 |
SCREW-HH Price: $1.29 |
| 47 |
817490508 |
SCREW LT Price: $3.99 |
| 48 |
324-4 |
SCREW-HH Price: $0.95 |
| 48 |
532135227 |
Spindle Asm LH (AYP part number) Price: $15.39 |
| 49 |
5-2390 |
DISCONTINUED Price: Call Us |
| 49 |
532135228 |
Spindle Asm RH Price: $12.97 |
| 50 |
5-1626 |
DISCONTINUED Price: Call Us |
| 50 |
874760612 |
BOLT Price: $1.99 |
| 51 |
5-1628 |
DISCONTINUED Price: Call Us |
| 51 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $59.99 |
| 52 |
3-9066 |
DISCONTINUED Price: Call Us |
| 52 |
810040500 |
LOCKWASHER Price: $2.99 |
| 53 |
3-9001 |
DISCONTINUED Price: Call Us |
| 53 |
873610500 |
This part replaces 873810500. Price: Call Us |
| 54 |
5-3270 |
DISCONTINUED Price: Call Us |
| 54 |
532003366 |
BEARING.STEERING.COLUMN Price: $1.99 |
| 55 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 55 |
532130468 |
DRAG LINK Price: $49.99 |
| 56 |
40-8100 |
EXHAUST MUFFLER Price: $140.10 |
| 56 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 57 |
3-9263 |
DISCONTINUED Price: Call Us |
| 57 |
873680600 |
LOCKNUT This part replaces 873610600. Price: $1.99 |
| 58 |
3217-7 |
NUT-HEX Price: $0.28 |
| 58 |
532155108 |
KIT/BUSH This part replaces 532001554. Price: $3.99 |
| 59 |
323-8 |
SCREW-HH Price: $1.20 |
| 59 |
817211008 |
Screw, Hex Wsh. Tap #10-16 x 1/2 (AYP part number) This part replaces 817431008. Price: $2.99 |
| 60 |
2812-4 |
REDUCER-PIPE Price: $9.67 |
| 60 |
532124130 |
Support, Assembly, Dash (AYP part number) Price: $12.22 |
| 61 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 61 |
532002751 |
CLIP T Price: $2.42 |
| 62 |
3290-153 |
DISCONTINUED Price: Call Us |
| 62 |
819131316 |
WASHER Price: $2.99 |
| 63 |
289-25 |
DISCONTINUED Price: Call Us |
| 63 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 64 |
288-3 |
DISCONTINUED Price: Call Us |
| 64 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $2.99 |
| 65 |
40-8070 |
DISCONTINUED Price: Call Us |
| 65 |
532132624 |
Pin, Axle 5/8 x 1.55/1.54 LG. (AYP part number) Price: $2.42 |
| 66 |
3-8946 |
DISCONTINUED Price: Call Us |
| 66 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532006855. Price: $3.99 |
| 67 |
221-709 |
Engine (Kohler Model K321S Type No. 60387) Price: Call Us |
| 67 |
874180512 |
SCREW Price: $3.99 |
| 68 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 68 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 69 |
873310500 |
NUT Price: $3.99 |
| 70 |
819272016 |
WASHER Price: $2.99 |
| 71 |
532122819 |
Thd. Form Washer Hd. Hex Screw (AYP part number) Price: $2.38 |
| 72 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
