| Ref | Part Number | Description |
|---|
| 1 |
117-8982 |
TANK-HYDRAULIC This part replaces 104-9254. Price: $1,846.02 |
| 2 |
532069180 |
Nut, Crownlock #10-24 Price: $2.69 |
| 2 |
68-6150 |
BREATHER Price: $27.22 |
| 3 |
532127533 |
Screen, Cover Price: $11.99 |
| 3 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 4 |
532400436 |
COVER ASM BAGGER This part replaces 532134678. Price: $212.99 |
| 4 |
94-9411 |
DIPSTICK Price: $42.51 |
| 5 |
532126840 |
Chute, Upper Price: $74.99 |
| 5 |
98-3917-01 |
BRACKET-FILTER Price: $45.78 |
| 6 |
818021008 |
Screw, Special #10-14 x 1/2 Price: $3.99 |
| 6 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 7 |
340-91 |
FITTING-STR Price: $36.83 |
| 7 |
532140572 |
Dump Bag Indicator Price: $4.99 |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 9 |
23-8910 |
STEM-BARB-90 Price: $153.60 |
| 9 |
819061216 |
Washer 3/16 x 3/4 x 16 Ga. Price: $2.69 |
| 10 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 10 |
532007206 |
Spacer, Split Price: $3.99 |
| 11 |
353-508 |
PLUG-HH Price: $7.96 |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 12 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 12 |
810071000 |
Washer, lock Price: $2.99 |
| 13 |
532109808 |
Latch, Chute Price: $2.69 |
| 13 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 14 |
93-7588 |
COVER-TANK Price: $37.60 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 15 |
532160793 |
Latch Hook Asm. This part replaces 532130760. Price: $7.99 |
| 16 |
532160793 |
Latch Hook Asm. This part replaces 532130759. Price: $7.99 |
| 16 |
93-7499 |
GASKET Price: $5.91 |
| 17 |
98-3931 |
HOSE-FORMED Price: $80.81 |
| 18 |
237-101 |
O-RING Price: $2.80 |
| 18 |
532162803 |
Chute, Lower Price: $67.99 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 20 |
2412-93 |
CLAMP-R Price: $1.02 |
| 20 |
871081010 |
Screw #10-24 x 5/8 This part replaces 871161010. Price: $3.49 |
| 21 |
532132796 |
Spring, Cover L.H. (black) Price: $2.99 |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 22 |
532133235 |
Spacer, Cover Price: $3.99 |
| 23 |
323-4 |
SCREW-HH Price: $1.02 |
| 23 |
532132983 |
Spring, Cover R.H. (gray) Price: $2.99 |
| 24 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 24 |
532180925 |
POST.SUPPORT.BAGGER.2BIN This part replaces 532126813. Price: $28.99 |
| 25 |
532063124 |
Locknut 5/16 x 18 Price: $0.99 |
| 25 |
63-8410 |
WASHER Price: $1.76 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 26 |
75-6870 |
HOSE-INLET, PUMP Price: $50.00 |
| 27 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 27 |
539976934 |
HCS.5/16-18X3/4 This part replaces 874760512. Price: $1.99 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
532170053 |
Bracket, Mounting Price: $9.99 |
| 29 |
532170165 |
Shoulder Bolt, Self Tapping Price: $2.99 |
| 30 |
532131137 |
Pin, Support Post Price: $6.99 |
| 31 |
532174083 |
Plug, Tubing End Price: $3.99 |
| 32 |
532134639 |
Bagger, Frame Price: $59.63 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 34 |
532127534 |
Gasket, Cover Price: $8.99 |
| 35 |
532183286 |
Container, Top This part replaces 532129585. Price: $17.99 |
| 36 |
532129586 |
Container, Bottom Price: $62.99 |
| 37 |
532134637 |
Seal, Cover Price: $14.52 |
| 38 |
532130895 |
Latch Handle, Cover Price: $3.99 |
| 39 |
532155857 |
Strip, Reinforcement Price: $9.99 |
| 40 |
871141008 |
Screw #10-24 x 1/2 Price: $2.99 |
| 41 |
532156006 |
Bagger, Support Tube Price: $38.99 |
| 42 |
532145186 |
Reinforcement Plate Price: $9.99 |
| 43 |
819112410 |
Washer 11/32 x 1.5 x 10 Ga. Price: $3.99 |
| 44 |
810040500 |
Washer, lock Price: $2.99 |
| 45 |
532128638 |
Nut, Wing Price: $3.99 |
| 46 |
874760536 |
Bolt, Hex 5/16-18 x 2-1/4 Price: $3.99 |
| 47 |
872110506 |
Carriage Bolt 5/16-18 x 3/4 Price: $3.99 |
