| Ref | Part Number | Description |
|---|
| 1 |
139-7531-03 |
CONTROL BOX ASM Price: $100.69 |
| 4 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 5 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 6 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
119-3470 |
ACTUATOR ARM ASM Price: $17.50 |
| 8 |
115-5099 |
BOLT-PIVOT Price: $2.32 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
120-2273 |
WASHER-NYLON Price: $1.54 |
| 11 |
136-5570-05 |
ARM-CONTROL Price: $22.86 |
| 12 |
117-1240 |
WASHER Price: $1.27 |
| 13 |
139-2556 |
BOLT-PIVOT Price: $2.83 |
| 14 |
119-8952 |
WASHER Price: $0.77 |
| 15 |
120-7950 |
SCREW-SHOULDER Price: $1.79 |
| 16 |
132-6853 |
DAMPER-NON CAVITATING Price: $22.72 |
| 17 |
138-7215 |
STUD-DAMPER Price: $1.46 |
| 18 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
133-7055 |
HANDLE-CONTROL, LH Price: $41.09 |
| 20 |
133-7057 |
HANDLE-CONTROL, RH Price: $41.09 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 22 |
323-6 |
SCREW-HH Price: $0.66 |
| 23 |
119-8948 |
PLATE-STOP, HYDRO Price: $1.42 |
| 24 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 29 |
138-7217 |
ROD-HYDRO Price: $8.29 |
| 30 |
138-7218 |
MOUNT-ROD, HYDRO Price: $7.95 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 32 |
138-7252 |
SPRING-COMPRESSION Price: $1.12 |
| 33 |
121-1753 |
PIN-ROD, HYDRO Price: $3.52 |
| 35 |
321-3 |
SCREW-HH Price: $0.28 |
| 36 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 37 |
119-8925 |
WASHER-BELLEVILLE Price: $0.80 |
