| Ref | Part Number | Description |
|---|
| 1 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 2 |
2412-133 |
CLAMP-R Price: $3.19 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
76-9460-03 |
DISCONTINUED This part replaces 76-9460. Price: Call Us |
| 4 |
77-3780 |
PIN ASM-LYNCH Price: $15.06 |
| 5 |
3290-282 |
RIVET-BLIND Price: $0.28 |
| 6 |
3256-49 |
WASHER-PLAIN Price: $0.33 |
| 7 |
76-9930 |
FOAM-CENTER Price: $7.40 |
| 8 |
82-4900 |
FOAM-SEAT, REAR Price: $71.75 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
76-9440 |
ROD-PROP, SEAT Price: $65.18 |
| 10 |
32128-33 |
NUT-HF Price: $0.25 |
| 11 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 12 |
37-2690 |
CAPACITOR Price: $155.98 |
| 12 |
532405472 |
RP_PULLEY ENGINE Price: $34.99 |
| 13 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 14 |
2412-74 |
R-CLAMP Price: $2.37 |
| 15 |
218-461 |
NUT-HH Price: $2.50 |
| 15 |
599306004 |
FUEL TANK, 3GAL, 2.25"NECK, 20 This part replaces 532438080. Price: $199.99 |
| 16 |
323-17 |
SCREW-HH Price: $2.05 |
| 17 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 18 |
237-30 |
O-RING Price: $2.50 |
| 18 |
532439208 |
CAP.ASM.FL.RITCH.3"E10.SYM.498 Price: $37.99 |
| 19 |
43-8610 |
GUIDE Price: $23.35 |
| 20 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
237-7 |
O-RING Price: $8.82 |
| 24 |
237-136 |
GROMMET Price: $3.52 |
| 25 |
80-7730 |
SPACER Price: $1.97 |
| 26 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 27 |
137-8085 |
SPRING-SEAT, COMPRESSION This part replaces 88-1420. Price: $8.86 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
70-1480 |
RELAY Price: $105.19 |
| 30 |
321-5 |
SCREW-HH Price: $0.22 |
| 31 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 32 |
116749 |
HORN This part replaces 48-4590. Price: $130.99 |
| 33 |
74-8910 |
DISCONTINUED Price: Call Us |
| 34 |
86-2860-03 |
COVER-BELT, UPPER This part replaces 86-2860. Price: $16.75 |
| 35 |
76-9480 |
SLEEVE-PIVOT, SEAT Price: $4.64 |
| 36 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 37 |
325-9 |
SCREW-HH Price: $1.87 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
322-2 |
SCREW-HH Price: $0.69 |
| 39 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
