| Ref | Part Number | Description |
|---|
| 1 |
34328B |
CYLINDER This part replaces 34328A. Price: Call Us |
| 2 |
27652 |
PIN Price: $1.58 |
| 3 |
32590 |
LOCK PLATE Price: Call Us |
| 4 |
32630 |
OIL SEAL Price: $6.00 |
| 5 |
34035 |
INT VALVE ST Price: $10.91 |
| 5 |
34036 |
INTAKE VALVE OS Price: Call Us |
| 6 |
27878A |
EXH VALVE STD Price: $16.51 |
| 6 |
27880A |
EXH VALVE OS Price: $34.25 |
| 7 |
27882 |
VALVE CAP Price: $1.26 |
| 7A |
35862 |
INT VALVE SEAL This part replaces 34689. Price: $6.54 |
| 8 |
27881 |
VALVE SPRING Price: $2.62 |
| 9 |
32581 |
VALVE CAP Price: $4.49 |
| 10 |
650662C |
SCREW This part replaces 650662B. Price: $2.60 |
| 11 |
33644B |
CRANKSHAFT This part replaces 33644A. Price: $115.61 |
| 12 |
29783 |
GROOVE PIN Price: $1.26 |
| 13 |
33245 |
GEAR Price: $8.94 |
| 14 |
34554 |
PISTON ASSY 020 Price: Call Us |
| 14 |
40012 |
PISTON ASSY 010 This part replaces 34553. Price: $57.66 |
| 14 |
40049 |
PISTON ASSY STD This part replaces 34552. Price: $56.41 |
| 14A |
34331A |
PISTON & PIN 20 Price: Call Us |
| 14A |
40012 |
PISTON ASSY 010 This part replaces 34330A. Price: $57.66 |
| 14A |
40049 |
PISTON ASSY STD This part replaces 34329A. Price: $56.41 |
| 15 |
34333 |
RING SET 010 Price: $23.45 |
| 15 |
34334 |
RING SET 020 Price: $27.52 |
| 15 |
40049 |
PISTON ASSY STD This part replaces 34332. Price: $56.41 |
| 16 |
27888 |
RET RING Price: $1.26 |
| 17 |
32591C |
CONN ROD--Discontinued Price: Call Us |
| 18 |
32589 |
KEY Price: $1.05 |
| 19 |
27275 |
CLIP Price: $1.26 |
| 19A |
29443 |
CLIP Price: $1.26 |
| 20A |
33581 |
SCREEN Price: $2.62 |
| 21 |
34034A |
VALVE LIFTER This part replaces 34034. Price: $7.41 |
| 22 |
34040 |
CAMSHAFT Price: $66.44 |
| 23 |
37342 |
GASKET This part replaces 33253. Price: $8.45 |
| 24 |
33580 |
MTG FLANGE Price: $106.09 |
| 25 |
29117 |
SCREW Price: $1.22 |
| 26 |
31356 |
OIL PUMP Price: $8.86 |
| 27 |
31950 |
OIL SEAL Price: $14.00 |
| 28 |
31927 |
PIPE PLUG Price: $1.26 |
| 29 |
650488 |
SCREW Price: $1.25 |
| 30 |
33992A |
FILLER TUBE Price: Call Us |
| 35 |
30668 |
GOV SHAFT Price: $1.26 |
| 36 |
31707A |
SPACER Price: $1.26 |
| 36A |
651080 |
WASHER This part replaces 30590A. Price: $1.24 |
| 37 |
30591 |
GEAR Price: $9.93 |
| 38 |
30588A |
GOV SPOOL Price: $1.26 |
| 39 |
29193 |
RET RING Price: $1.26 |
| 40 |
33577 |
GOVERNOR ROD Price: $5.21 |
| 41 |
32651 |
GOV LEVER Price: $1.26 |
| 42 |
31335 |
CLAMP Price: $1.26 |
| 43 |
651018 |
SCREW This part replaces 650548. Price: $1.18 |
| 44 |
28277 |
WASHER Price: $1.26 |
| 45 |
30088A |
SCREW Price: $1.26 |
| 46 |
34926 |
INTAKE PIPE This part replaces 33862. Price: $26.71 |
| 47 |
27915A |
GASKET This part replaces 27915. Price: $3.95 |
| 48 |
33261 |
BRACKET Price: $2.62 |
| 49 |
29752 |
NUT Price: $1.26 |
| 50 |
30200 |
SCREW Price: $3.25 |
| 52 |
650738 |
SCREW Price: $2.60 |
| 53 |
33263 |
GASKET This part replaces 33861. Price: $1.00 |
| 54 |
650378 |
SCREW Price: $1.25 |
| 55 |
650378 |
SCREW Price: $1.25 |
| 56 |
33865B |
CONTROL ASSY Price: $13.15 |
| 56A |
610973 |
TERMINAL Price: $2.60 |
| 57A |
31342 |
COMP SPRING Price: $3.95 |
| 58 |
651029 |
SCREW This part replaces 650549. Price: $1.22 |
| 59 |
28942 |
SCREW Price: $0.88 |
| 59A |
27793 |
CLIP Price: $1.26 |
| 60 |
33151 |
GOV LINK Price: $1.26 |
| 61 |
31361 |
GOV SPRING Price: $1.18 |
| 62 |
33860 |
GOV LINK Price: $1.26 |
| 72 |
34923A |
GASKET This part replaces 34041. Price: $5.63 |
| 73 |
34030B |
CYL HEAD This part replaces 34030. Price: Call Us |
| 74 |
33272D |
COVER This part replaces 33272. Price: $5.21 |
| 75 |
6021A |
SCREW Price: $1.26 |
| 75 |
650692 |
SCREW--NLA Price: Call Us |
| 75 |
650711 |
SCREW Price: $1.25 |
| 75 |
650727 |
SCREW Price: $2.60 |
| 77 |
650273 |
SCREW This part replaces 650713. Price: $1.25 |
| 77 |
650737 |
SCREW Price: $1.25 |
| 77 |
650738 |
SCREW Price: $2.60 |
| 79 |
650691 |
WASHER Price: $1.25 |
| 80 |
27896A |
GASKET This part replaces 27896. Price: $1.00 |
| 81 |
28423 |
BREATHER Price: $9.29 |
| 82 |
28424 |
ELEMENT Price: $2.62 |
| 83 |
650128 |
SCREW Price: $3.60 |
| 84 |
28425 |
VALVE COVER Price: $5.21 |
| 85 |
35350 |
TUBE This part replaces 27627. Price: $4.57 |
| 86 |
33636 |
SPARK PLUG This part replaces 34251. Price: $5.05 |
| 87 |
33273A |
EXTENSION This part replaces 33273. Price: $5.21 |
| 88 |
30063 |
SCREW This part replaces 30688. Price: $1.26 |
| 89 |
650128 |
SCREW Price: $3.60 |
| 90 |
33635C |
BLOWER HSG This part replaces 33635A. Price: $103.31 |
| 91 |
29747C |
SCREW/LOCKWASHER ASSEMBLY This part replaces 29747A. Price: $1.26 |
| 93 |
650788 |
SCREW Price: $1.25 |
| 94 |
37861 |
BAFFLE This part replaces 29536. Price: $8.03 |
| 95 |
650561 |
SCREW Price: $1.25 |
| 96 |
29752 |
NUT Price: $1.26 |
| 97 |
33583B |
FUEL TANK-NLA This part replaces 33583A. Price: Call Us |
| 98 |
33032 |
FUEL CAP This part replaces 34118. Price: $5.31 |
| 98 |
34210 |
FUEL CAP Price: $5.77 |
| 99 |
26460 |
CLAMP Price: $1.19 |
| 100 |
29774 |
FUEL LINE Price: $2.78 |
| 100 |
30705 |
FUEL LINE Price: $11.47 |
| 100 |
30962 |
FUEL LINE Price: $22.04 |
| 103 |
34185B |
MUFFLER This part replaces 33280A. Price: $28.95 |
| 104 |
31588 |
LOCK PLATE Price: $2.00 |
| 105 |
650729 |
SCREW Price: $1.25 |
| 109 |
33662 |
CUP & SCREEN Price: $18.20 |
| 110 |
8116 |
NUT Price: $1.23 |
| 111 |
650815 |
WASHER Price: $1.25 |
| 115 |
650489 |
SCREW Price: Call Us |
| 115 |
650516 |
SCREW Price: $1.18 |
| 118 |
28763 |
SCREW Price: $1.16 |
| 119 |
33876 |
GASKET Price: $3.59 |
| 122 |
34231 |
GROUND WIRE Price: $2.55 |
| 123 |
33013 |
COVER Price: $2.62 |
| 124 |
650760 |
SCREW Price: $1.17 |
| 141 |
33629 |
GASKET Price: $1.26 |
| 142 |
34912 |
GASKET This part replaces 33634. Price: $1.22 |
| 144 |
650707 |
SCREW Price: $1.20 |
| 145 |
650762 |
SCREW Price: $3.86 |
| 146 |
33631 |
AIR CLEANER Price: $4.23 |
| 147 |
33630 |
BRACKET Price: Call Us |
| 148 |
34425 |
CLEANER BODY Price: $10.47 |
| 149 |
34424 |
CLEANER COV Price: $7.04 |
| 150 |
33632A |
CLEANER COV Price: $17.47 |
| 195 |
36261 |
DECAL This part replaces 34346. Price: Call Us |
| 195A |
34686A |
DECAL This part replaces 34686. Price: $1.00 |
| 196 |
30547A |
BREAKER SET Price: $12.55 |
| 197 |
30548B |
CONDENSER Price: $8.40 |
| 199 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 200 |
631863C |
SERVICE CARB This part replaces 631981. Price: $89.70 |
| 201 |
610842 |
MAGNETO Price: Call Us |
| 202 |
590685B |
STARTER This part replaces 590479. Price: $48.62 |
