| Ref | Part Number | Description |
|---|
| 1 |
127-3752 |
CASE-GEAR Price: $631.77 |
| 1 |
532170863 |
CONTROL,TH/CH FLAG This part replaces 532155274. Price: $27.99 |
| 2 |
125-6995 |
PIN Price: $5.45 |
| 2 |
596582501 |
Bolts This part replaces 817720410. Price: $2.99 |
| 3 |
125-6972 |
COVER-FILLER Price: $10.14 |
| 4 |
125-7107 |
PIPE Price: $8.10 |
| 5 |
125-6909 |
O-RING Price: $2.55 |
| 5 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 6 |
127-2973 |
O-RING Price: $3.16 |
| 6 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 7 |
127-3753 |
JOINT Price: $18.27 |
| 8 |
125-7197 |
O-RING Price: $2.55 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 532150176. Price: $4.99 |
| 9 |
125-7214 |
BOLT Price: $3.77 |
| 10 |
127-3754 |
PIPE Price: $68.96 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
125-7197 |
O-RING Price: $2.55 |
| 12 |
127-3024 |
GEARCASE COVER ASM Price: $475.19 |
| 14 |
125-6944 |
SEAL-OIL Price: $31.03 |
| 14 |
813280336 |
Nipple, Pipe 3/8 NPT x 4-1/2 Price: $2.42 |
| 15 |
125-6977 |
COVER Price: $8.10 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 16 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 17 |
125-7214 |
BOLT Price: $3.77 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 18 |
125-7217 |
BOLT Price: $4.58 |
| 19 |
125-7218 |
BOLT Price: $3.48 |
| 20 |
125-7222 |
BOLT Price: $4.99 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 25 |
532145996 |
CONTROL, CHOKE Price: $19.99 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
532151346 |
FUEL TANK 3.5G Price: $84.99 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 39 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 40 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
