| Ref | Part Number | Description |
|---|
| 1 |
703-05441A |
Muffler Mount Bracket Price: $48.35 |
| 2 |
710-0227 |
Hex Washer Screw, #8-18 x .500 Price: $3.90 |
| 3 |
710-1017 |
Screw, 1/4-14 x .625 Price: $7.26 |
| 4 |
710-3157A |
Hex Screw, 7/16-20 x 3.25 Price: $9.67 |
| 5 |
710-0599 |
Hex Washer Screw, 1/4-20 x .500 Price: $3.86 |
| 6 |
710-04683C |
SCREW 3/8-16 x 1 This part replaces 710-04683. Price: $5.67 |
| 7 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 8 |
710-3217 |
Machine Screw, #8-32 x .375 Price: $5.94 |
| 9 |
712-0142 |
Hex Nut, #8-32 Price: $3.90 |
| 10 |
712-0271 |
Sems Nut, 1/4-20 Price: $3.78 |
| 11 |
712-04063 |
Flange Lock Nut, 5/16-18 Price: $3.56 |
| 13 |
917-04376A |
Electric PTO Clutch Price: $461.82 |
| 14 |
726-0197 |
Cable Tie Price: $3.22 |
| 15 |
726-0205 |
Hose Clamp Price: $3.71 |
| 16 |
731-04914 |
Throttle Control Knob Price: $11.56 |
| 17 |
736-0148 |
Lock Washer, 3/8 Price: $3.19 |
| 18 |
936-0171 |
Lock Washer, 7/16 Price: $3.86 |
| 20 |
746P04539 |
THROTTLE/CHOKE CABLE 41.5" This part replaces 746-04539. Price: $37.67 |
| 22 |
751-11053B |
EXHAUST DELECTOR (LONG) This part replaces 751-11053. Price: $4.64 |
| 23 |
951-0616B |
MUFFLER (DUAL INLET) This part replaces 751-0616B. Price: $143.87 |
| 24 |
751-10253 |
Exhaust Pipe, LH Price: $63.72 |
| 25 |
751-10254 |
Exhaust Pipe, RH Price: $82.97 |
| 26 |
751-10291D |
OIL DRAIN HOSE W/VIBRA SEAL This part replaces 751-10291A. Price: $46.52 |
| 27 |
751-10349 |
Fuel Hose Price: $8.11 |
| 28 |
756-04376 |
Engine Pulley Price: $39.30 |
| 29 |
751-12089-28 |
Hose Vent, 3/16 EPA Price: $7.79 |
| 30 |
951-08858 |
FUEL TANK (2.82 GAL) This part replaces 951-04209B. Price: $169.99 |
| 32 |
736-0277 |
Flat Washer, 1.03 x 1.620 x .095 Price: $3.90 |
| 33 |
710-1314A |
Screw, 5/16-18 x .750 Price: $4.05 |
