| Ref | Part Number | Description |
|---|
| 1 |
3-8394 |
DISCONTINUED Price: Call Us |
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK Price: $22.99 |
| 2 |
3-7138 |
DISCONTINUED Price: Call Us |
| 2 |
817240408 |
SCREW Price: $3.99 |
| 3 |
3296-45 |
NUT-HEX Price: $3.79 |
| 4 |
325-3 |
SCREW-HH Price: $1.49 |
| 4 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $29.99 |
| 5 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 6 |
322-10 |
SCREW-HH Price: $0.70 |
| 7 |
20-4890 |
DISCONTINUED Price: Call Us |
| 8 |
3210-3 |
SCREW-HH Price: $5.29 |
| 9 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
4-2320 |
DISCONTINUED Price: Call Us |
| 11 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 12 |
117127 |
TIRE (16 X 6.5-8) 2-PLY -2 WHEEL AXEL This part replaces 231-39. Price: $107.13 |
| 13 |
3-2889 |
DISCONTINUED Price: Call Us |
| 13 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 15 |
3-8014 |
AXLE SHAFT Price: $49.11 |
| 16 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 17 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 18 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 19 |
242-39 |
WHEEL ASM Price: $244.32 |
| 20 |
242-33 |
DISCONTINUED Price: Call Us |
| 21 |
323-6 |
SCREW-HH Price: $0.66 |
| 22 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 23 |
3-6506 |
DISCONTINUED Price: Call Us |
| 23 |
532169837 |
SHIELD.BROWNING.DBR.GUARD Price: $7.99 |
| 24 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 25 |
5-0460 |
STRG SWAGED CABLE ASM Price: $96.86 |
| 26 |
3-8011 |
DISCONTINUED Price: Call Us |
| 27 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
242-32 |
LUG NUT Price: $4.77 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
32146-1 |
DISCONTINUED Price: Call Us |
| 31 |
5-5560 |
DISCONTINUED Price: Call Us |
| 31 |
581289901 |
FUEL.TANK.ASM.1.5.GAL.NON-EPA This part replaces 532407545. Price: $54.99 |
| 32 |
5-1257 |
DISCONTINUED Price: Call Us |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $14.99 |
| 33 |
5-2106 |
PVT CSTR/SFT WA*RO Price: $291.44 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
32128-13 |
NUT-HF Price: $1.79 |
| 35 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 36 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 37 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 37 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 38 |
3-6493 |
DISCONTINUED Price: Call Us |
| 39 |
3217-6 |
NUT-HEX Price: $1.19 |
| 40 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 40 |
532124028 |
GROMMET T Price: $3.99 |
| 41 |
32121-48 |
PIN-SPRING Price: $0.61 |
| 43 |
20-4900 |
DISCONTINUED Price: Call Us |
| 44 |
3-7993 |
DISCONTINUE Price: Call Us |
| 45 |
5-5540 |
DISCONTINUED Price: Call Us |
| 46 |
325-9 |
SCREW-HH Price: $1.87 |
| 47 |
322-13 |
SCREW-HH Price: $2.73 |
| 48 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 49 |
3290-239 |
DISCONTINUED Price: Call Us |
| 50 |
3-6501 |
DISCONTINUED Price: Call Us |
| 51 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 72 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
