| Ref | Part Number | Description |
|---|
| 1 |
323-4 |
SCREW-HH Price: $1.02 |
| 1 |
530031163 |
Bar Wrench Price: $4.99 |
| 2 |
23-2100 |
DISCONTINUED Price: Call Us |
| 2 |
530037793 |
Foam-Air Filter Price: $1.99 |
| 3 |
21-3600 |
FOAM-SUPPORT, TANK Price: $25.75 |
| 3 |
530016101 |
Nut Price: $1.99 |
| 4 |
43-9110 |
GAS TANK ASM This part replaces 37-9530. Price: $439.33 |
| 4 |
530047604 |
Air Filter Housing Price: $1.99 |
| 5 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 5 |
530071621 |
Kit-Carburetor (WT-625) This part replaces 530069722. Price: $54.99 |
| 6 |
3274-51 |
SCREW-HSH Price: $0.41 |
| 6 |
530019217 |
Carb. Gasket Price: $3.33 |
| 7 |
37-9550 |
STRAP-TANK, FUEL Price: $46.74 |
| 7 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 8 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 8 |
530047824 |
Carb. Adapter Kit (Inc. 9 & 17) Price: $3.33 |
| 9 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 9 |
530016094 |
Screw Price: $3.33 |
| 10 |
23-2080 |
DISCONTINUED Price: Call Us |
| 10 |
530016153 |
Screw Price: $1.99 |
| 11 |
256-237 |
BUSHING Price: $14.99 |
| 11 |
530047578 |
Cylinder Shield Price: $3.33 |
| 12 |
321-6 |
SCREW-HH Price: $0.25 |
| 12 |
530038318 |
Limiter Cap-High Price: $1.99 |
| 13 |
37-9540 |
DISCONTINUED Price: Call Us |
| 13 |
530038317 |
Limiter Cap-Low Price: $1.99 |
| 14 |
21-3610 |
FOAM-SUPPORT, TANK Price: $20.11 |
| 14 |
530038340 |
Grommet-Carb Adjust. Price: $0.32 |
| 15 |
2412-41 |
CLAMP-R Price: $4.82 |
| 15 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 16 |
110-4100 |
HOSE-FUEL This part replaces 23-2140. Price: $28.86 |
| 16 |
530069216 |
Primer Line Kit (Small Dia) Price: $3.99 |
| 17 |
2412-6 |
CLAMP-HOSE Price: $4.57 |
| 17 |
530019210 |
Air Box Seal Price: $0.40 |
| 18 |
353-536 |
DISCONTINUED Price: Call Us |
| 18 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 19 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 19 |
530019208 |
Gasket Price: $3.33 |
| 20 |
28-5640 |
SPECIAL WASHER Price: $3.58 |
| 20 |
530038749 |
CYLINDER PLATED This part replaces 530069702. Price: $34.99 |
| 20 |
530069720 |
MODEL 260 Price: $17.52 |
| 21 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 21 |
530069701 |
MODEL 230 Price: $22.99 |
| 21 |
530069719 |
MODEL 260 Price: $19.99 |
| 22 |
23-7270 |
NUT-LUG Price: $10.37 |
| 22 |
530029805 |
MODEL 230 Price: $2.99 |
| 22 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 23 |
217-105 |
DISCONTINUED X-REF Price: Call Us |
| 23 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 24 |
5108 |
VALVE This part replaces 232-31. Price: $6.29 |
| 24 |
545113101 |
CRANKSHAFT ASSY This part replaces 530038507. Price: $54.99 |
| 25 |
43-7630 |
AXLE WA *RO This part replaces 33-4360. Price: $4,368.18 |
| 25 |
530047179 |
Seal & Bearing Ass'y. Price: $3.33 |
| 26 |
3234-15 |
SCREW-HHF Price: $1.97 |
| 26 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 27 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 28 |
3217-6 |
NUT-HEX Price: $1.19 |
| 28 |
530015780 |
Screw-Type II This part replaces 530016090. Price: $1.99 |
| 29 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
530069608 |
Engine Gasket Kit (Inc. 6,17,19,33) Price: $5.99 |
| 30 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 30 |
530047603 |
Wire Harness Ass'y. Price: $3.33 |
| 31 |
2811-9 |
FITTING-ELBOW-90 Price: $15.86 |
| 31 |
530095646 |
Assy-Fuel Pickup This part replaces 530014362. Price: $2.99 |
| 32 |
289-37 |
NIPPLE-PIPE Price: $21.68 |
| 32 |
530037652 |
Heat Insulator Price: $1.99 |
| 33 |
23-5180 |
DIPSTICK ASM Price: $69.61 |
| 33 |
530019221 |
Muffler Gasket Price: $1.99 |
| 34 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 34 |
530038237 |
Muffler Back Plate Price: $3.33 |
| 35 |
108-3282 |
HOSE-FUEL This part replaces 37-9560. Price: $36.93 |
| 35 |
530071904 |
MUFFLER This part replaces 530047207. Price: $14.99 |
| 36 |
22-7810 |
SPACER Price: $16.90 |
| 36 |
530037813 |
Diffuser This part replaces 530037245. Price: $1.99 |
| 37 |
530036103 |
Spark Arrestor Screen Price: Call Us |
| 38 |
530016132 |
Screw Price: $1.99 |
| 39 |
530071905 |
KIT This part replaces 530039167. Price: $37.99 |
| 40 |
530015814 |
Screw-Line Limiter This part replaces 530015905. Price: $1.99 |
| 41 |
530047442 |
Ground Strap Price: $1.99 |
