| Ref | Part Number | Description |
|---|
| 1 |
323-7 |
SCREW-HH Price: $0.65 |
| 1 |
583951401 |
PEDAL PLATE ASSY HYDROSTATIC K This part replaces 544126001. Price: $139.99 |
| 2 |
105-4886 |
NUT-TINNERMAN Price: $2.37 |
| 2 |
586727401 |
KNOB, THREADED This part replaces 535473701. Price: $9.99 |
| 3 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 3 |
506570104 |
BOLT Price: $4.99 |
| 4 |
506938301 |
SHOCK ABSORBER Price: $149.99 |
| 4 |
63-9750 |
MOUNT Price: $18.92 |
| 5 |
506938402 |
NEEDS DESCRIPTION Price: Call Us |
| 5 |
63-8410 |
WASHER Price: $1.76 |
| 6 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 6 |
735310920 |
E-RING 5 Price: $3.99 |
| 7 |
104-7201 |
NUT-HF Price: $0.69 |
| 7 |
506946301 |
SPRING Price: $7.99 |
| 8 |
1-303352 |
WASHER-SPINDLE Price: $1.20 |
| 8 |
506992702 |
NEEDS DESCRIPTION Price: Call Us |
| 8 |
576712101 |
BRAKE WIRE This part replaces 535489601. Price: $32.99 |
| 9 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 9 |
735310920 |
E-RING 5 Price: $3.99 |
| 10 |
119-1409-03 |
MOUNT-PLATE Price: $20.15 |
| 10 |
506538404 |
NEEDS DESCRIPTION Price: Call Us |
| 11 |
323-20 |
SCREW-HH Price: $1.28 |
| 12 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 12 |
582152001 |
CONTROL CABLE TRANSMISSION This part replaces 574411201. Price: $69.99 |
| 13 |
115-0280 |
STEER SELECTOR VALVE ASM Price: $576.12 |
| 13 |
731231401 |
NUT Price: $1.99 |
| 14 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 14 |
578776801 |
CONNECTOR, BALL JOINT This part replaces 506557301. Price: $9.99 |
| 15 |
321-11 |
SCREW-HH Price: $0.36 |
| 15 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 16 |
131-3352-03 |
PLATE-MOUNT, VALVE Price: $11.97 |
| 16 |
506800001 |
Bracket Price: $21.19 |
| 17 |
117-2247 |
CROSS-TRAX TRACTION VALVE ASM Price: $1,280.98 |
| 17 |
535475316 |
SCREW Price: $2.99 |
| 18 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 18 |
732211401 |
LOCKNUT M5 Price: $2.99 |
| 19 |
323-8 |
SCREW-HH Price: $1.20 |
| 19 |
506566501 |
CLAMP Price: $2.99 |
| 29 |
506538501 |
Arm Price: $22.27 |
| 30 |
506538601 |
Bracket Price: $18.98 |
| 31 |
506538901 |
Spring Price: $3.61 |
| 32 |
506538801 |
Pin Price: $7.33 |
| 33 |
735583501 |
CLIP Price: $12.99 |
| 34 |
506538704 |
KNOB, RED Price: $2.99 |
| 35 |
729532971 |
Screw Price: $1.80 |
