| Ref | Part Number | Description |
|---|
| 1 |
76-5070 |
OIL PUMP ASM Price: $729.22 |
| 2 |
720182520 |
PIN This part replaces 720124020. Price: $1.99 |
| 2 |
76-5080 |
PISTON Price: $14.39 |
| 3 |
588086001 |
THROTTLE LOCKOUT This part replaces 506222802. Price: $9.99 |
| 3 |
76-5090 |
SPRING-PISTON Price: $4.54 |
| 4 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 4 |
595835701 |
SPRING THROTTLE TRIGGER This part replaces 506379501. Price: $12.99 |
| 5 |
506371302 |
THROTTLE ROD This part replaces 506371301. Price: $14.99 |
| 5 |
76-5100 |
BOLT-SHOULDER Price: $5.63 |
| 6 |
588086201 |
THROTTLE CONTROL This part replaces 506372003. Price: $9.99 |
| 7 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 8 |
504357201 |
SINTER PLUG Price: $4.99 |
| 8 |
74-7910 |
SCREW - HEX HD Price: $2.92 |
| 9 |
33113-025 |
SCREW-HH This part replaces 48-7640. Price: $1.97 |
| 9 |
544324929 |
Fuel Hose Price: Call Us |
| 10 |
503164001 |
VALVE Price: $9.99 |
| 10 |
76-5150 |
DISCONTINUED Price: Call Us |
| 11 |
544393201 |
HOSE CLIP Price: $3.99 |
| 11 |
76-5160 |
DISCONTINUED Price: Call Us |
| 12 |
501371301 |
LID Price: $3.99 |
| 13 |
503226504 |
NUT Price: $4.99 |
| 14 |
506386702 |
GROUND SUPPORT Price: $3.99 |
| 15 |
503214516 |
SCREW Price: $3.99 |
| 16 |
581756203 |
FUEL HOSE This part replaces 544325003. Price: $7.99 |
| 18 |
506271101 |
CAP Price: $3.99 |
| 19 |
506264101 |
FILTER Price: $8.99 |
| 20 |
544229002 |
CHOKE CONTROL Price: $9.99 |
| 21 |
506378001 |
GROMMET Price: $7.99 |
| 22 |
503212810 |
SCREW Price: $2.99 |
| 23 |
506318604 |
STOP SWITCH This part replaces 506318602. Price: $19.99 |
| 28 |
506292101 |
GASKET Price: $4.99 |
| 29 |
503578901 |
TANK LOCK Price: $4.99 |
| 30 |
506394602 |
CAP Price: $3.99 |
| 31 |
506381501 |
HEAT SHIELD Price: $4.99 |
| 32 |
503215420 |
SCREW Price: $3.99 |
| 33 |
506371902 |
BASE PLATE Price: $9.99 |
| 35 |
544061201 |
SCREW Price: $3.99 |
| 36 |
544238201 |
BAND Price: $4.99 |
