| Ref | Part Number | Description |
|---|
| 1 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 1 |
725-3185 |
HARNESS-INDICATOR Not Available Price: |
| 2 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
2412-109 |
CLIP-J Price: $3.82 |
| 3 |
725-3205 |
HARNESS-PEDESTAL Not Available Price: |
| 4 |
237-100 |
GROMMET Price: $9.73 |
| 4 |
925-1365 |
Bulb, Indicator This part replaces 725-1365. Price: $9.56 |
| 5 |
104-5232 |
CLIP-WIRE This part replaces 60-0930. Price: $3.13 |
| 5 |
925-3159 |
HOUR METER Not Available This part replaces 725-3159. Price: |
| 6 |
710-0936 |
SCREW #6-20 x .625 Not Available Price: |
| 7 |
725-3066 |
SWITCH Not Available Price: |
| 7 |
82-9760 |
WIRE HARNESS - GAUGES Price: $202.94 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 8 |
712-3052 |
LOCK NUT #4-40 Not Available Price: |
| 9 |
711-3259 |
SCREW-SWITCH Not Available Price: |
| 9 |
82-9790 |
HARNESS Price: $69.81 |
| 10 |
82-9810 |
DISCONTINUED Price: Call Us |
| 10 |
925-3163 |
Switch, Ignition This part replaces 725-3163. Price: $44.93 |
| 11 |
712-3013 |
NUT-IGNITION SWITCH Not Available Price: |
| 12 |
82-9940 |
HARNESS Price: $22.70 |
| 12 |
925-0201 |
Key This part replaces 759-3476A. Price: $8.70 |
| 13 |
925-0893 |
Switch, PTO This part replaces 725-0893. Price: $72.43 |
| 14 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 14 |
82-9800 |
DISCONTINUED Price: Call Us |
| 15 |
58-3850 |
CABLE Price: $80.83 |
| 15 |
925-3191A |
Switch, Plunger This part replaces 725-3191. Price: $47.64 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
735-3036 |
BOOT-SWITCH Not Available Price: |
| 16 |
75-1370 |
CABLE-BATTERY, POSITIVE Price: $74.84 |
| 17 |
92-5685 |
DISCONTINUED Price: Call Us |
| 17 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 18 |
725-3019 |
CABLE ASSEMBLY-TAIL LAMP Not Available Price: |
| 18 |
82-9750 |
HARNESS Price: $24.36 |
| 19 |
725-3020 |
BULB Not Available Price: |
| 20 |
725-3018 |
Lens Assy, Tail Light Price: Call Us |
| 21 |
2412-131 |
R-CLAMP-CABLE Price: $5.02 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
86-6400 |
DIODE F/W ENGINE Price: $130.34 |
| 25 |
2412-74 |
R-CLAMP Price: $2.37 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 26 |
37-2690 |
CAPACITOR Price: $155.98 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
38-2860 |
RESISTOR- 5 OHM Price: $71.95 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
58-6860 |
CON. BODY/PINS F/W Price: $5.90 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 29 |
48-7880 |
NUT-HEX Price: $0.25 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
581023101 |
HARNESS.TEX.DASH.MAN.REAR BATT Price: $32.99 |
| 43 |
582042802 |
Solenoids This part replaces 582042801. Price: $22.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
581023401 |
HARNESS.PIGTAIL.VARIATOR.SD Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
