| Ref | Part Number | Description |
|---|
| 1 |
125-7091 |
CRANKSHAFT ASM Price: $2,915.83 |
| 1 |
532185382 |
DECK SVC 50".BLACK This part replaces 532136457. Price: $549.99 |
| 2 |
125-6995 |
PIN Price: $5.45 |
| 2 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 3 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 4 |
125-6937 |
GEAR Price: $205.45 |
| 4 |
532007631 |
RUNNER LH This part replaces 532125074. Price: $14.99 |
| 5 |
125-7185 |
KEY Price: $2.16 |
| 5 |
532138457 |
BRACKET SWAY BAR Price: $9.99 |
| 6 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 7 |
125-7182 |
PIN-SPRING Price: $3.77 |
| 7 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 8 |
125-6925 |
V-PULLEY Price: $255.74 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
125-7109 |
WASHER Price: $19.67 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
125-6956 |
BOLT Price: $40.22 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
125-6951 |
BOLT Price: $6.77 |
| 11 |
532137380 |
BLADE.50".HI-LIFT Price: $19.99 |
| 12 |
127-3160 |
FLYWHEEL ASM Price: $1,222.30 |
| 12 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 13 |
532137553 |
SHAFT.ASM.W/BEARING Price: $32.99 |
| 14 |
125-6943 |
GEAR Price: $137.73 |
| 14 |
532137152 |
HOUSING.MANDREL.44/46" VENT Price: $34.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
127-3097 |
PISTON ASM Price: $292.63 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 17 |
532106735 |
ROD-HINGE T Price: $8.99 |
| 18 |
127-3098 |
PISTON RING ASM Price: $90.40 |
| 18 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 19 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 20 |
532123713 |
SPRING TORSION Price: $6.99 |
| 21 |
531155201 |
SERVICE KIT BRACKET BRACKET This part replaces 532137607. Price: $2.99 |
| 22 |
532110452 |
NUT PUSH M Price: $2.99 |
| 23 |
532110509 |
SHIELD.DEFLECTOR.MOWER.50"BLK. Price: $27.99 |
| 24 |
125-7030 |
PIN Price: $43.23 |
| 24 |
532136320 |
RUNNER RH Price: $8.99 |
| 25 |
125-7180 |
RING Price: $2.39 |
| 25 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 26 |
125-7242 |
CONNECTING ROD ASM Price: $467.89 |
| 27 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 28 |
532132823 |
IDLER SPRING SPACER Price: $5.99 |
| 29 |
125-6955 |
BOLT Price: $20.62 |
| 29 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 30 |
125-7018 |
PIN-CRANK Price: $20.94 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 31 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 32 |
125-6997 |
PIN-PISTON Price: $21.73 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532129861. Price: $14.99 |
| 33 |
125-7019 |
PIN-CRANK (.25) Price: $20.96 |
| 33 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 34 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 35 |
127-3099 |
PISTON ASM (0.25 O.S.) Price: $267.86 |
| 35 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 36 |
596728201 |
Bolts This part replaces 872110608. Price: $3.99 |
| 37 |
532137166 |
STIFFENER ARM Price: $4.99 |
| 38 |
597024901 |
Keepers This part replaces 532137554. Price: $3.99 |
| 39 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 40 |
532136572 |
PULLEY.DRIVEN.44" Price: $27.99 |
| 42 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 43 |
532136460 |
ARM.IDLER.SEC.44" Price: $5.99 |
| 44 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 45 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 46 |
582740701 |
BOLT This part replaces 874760628. Price: $4.99 |
| 47 |
532137200 |
COVER MANDRELL Price: $21.99 |
| 48 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 49 |
532136574 |
COVER.MANDREL.LH.44" Price: $19.99 |
| 50 |
532137272 |
ARM.IDLER.PRIMARY Price: $4.99 |
| 52 |
532139245 |
PULLEY IDLER Price: $32.99 |
| 53 |
532137789 |
SHIELD IDLER Price: $4.99 |
| 54 |
532139573 |
V-BELT.PRMRY 46/50 VENT.BLK BK Price: $44.99 |
| 55 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 56 |
532138687 |
SPRING Price: $3.99 |
| 57 |
532136577 |
BAR.ASM.GUAGE.WHEEL Price: $9.99 |
| 58 |
532105455 |
WHEEL.GAUGE.BLK.4.93 Price: $14.99 |
| 59 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 60 |
532139031 |
PIN.CLEVIS Price: $4.99 |
| 61 |
532136573 |
BRACKET.GUAGE.WHEEL Price: $4.99 |
| 62 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 63 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 64 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 65 |
532102403 |
IDLER-FLAT T Price: $34.99 |
| 66 |
532156009 |
KEEPER, BELT IDLER 44/50 This part replaces 532139622. Price: $5.99 |
| 67 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 93 |
819171512 |
Washer 17/32 x 15/16 x 12 Gauge Price: $3.99 |
| 94 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $7.99 |
| 96 |
531154101 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532132273. Price: $12.99 |
| 97 |
819171416 |
Washer 1 17/32 X 7/8 X 16 Ga Price: $3.99 |
| 98 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 99 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 532143651 |
KIT.MANDREL.ASM.44"/46/50"SRVC |
Price: $89.99 532143651 |
| 532181689 |
DECK.ASM |
SVC 50".HP.WID GA/WHL This part replaces 532141051. Price: $899.99 532181689 |
