| Ref | Part Number | Description |
|---|
| 1 |
3274-69 |
SCREW-HSBH Price: $0.43 |
| 1 |
532416155 |
FRAME.WELD.PNT.998TGP Price: $43.99 |
| 2 |
107-2554 |
DECAL-PANEL, CONTROL This part replaces 93-8061. Price: $41.00 |
| 2 |
532410877 |
PAN.BOTTOM.PLASTIC Price: $19.99 |
| 2 |
83-2570 |
DISCONTINUED Price: Call Us |
| 2 |
KB-15852-73520 |
FLANGE-WAT Not Available Price: |
| 3 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 3 |
83-2030 |
PLATE-FILLER Price: $19.19 |
| 3 |
KB-15852-73550 |
BEARING-WA Not Available Price: |
| 4 |
83-0820 |
GAUGE - AMMETER Price: $76.09 |
| 5 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 5 |
KB-15852-73050 |
SEAL Not Available Price: |
| 6 |
83-1660 |
SWITCH-3 POSITION Price: $98.62 |
| 6 |
KB-19069-73510 |
Impeller, Water Pump Price: Call Us |
| 7 |
218-594 |
FUSE-20 AMP Price: $3.02 |
| 7 |
KB-15852-73340 |
WATER PIPE Not Available Price: |
| 8 |
83-1100 |
MAIN HARNESS Price: $437.84 |
| 8 |
KB-16851-73430 |
GASKET-WATER PUMP Not Available This part replaces KB-15841-73430. Price: |
| 9 |
94-6960 |
MOUNTING - CLAMP Price: $2.60 |
| 10 |
3217-27 |
NUT-HEX Price: $0.25 |
| 11 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 12 |
83-0030 |
CONTROL-THROTTLE Price: $39.07 |
| 13 |
83-0040 |
CONTROL-CHOKE Price: $36.29 |
| 14 |
83-0020 |
SWITCH-IGNITION Price: $56.91 |
| 15 |
3254-5 |
WASHER-LOCK Price: $0.49 |
| 16 |
218-461 |
NUT-HH Price: $2.50 |
| 17 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 18 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 19 |
218-498 |
NUT-LOCK Price: $0.68 |
| 20 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 21 |
321-5 |
SCREW-HH Price: $0.22 |
| 23 |
83-1530 |
BRACKET-SUPPORT, BUZZER Price: $13.54 |
| 24 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 25 |
80-9330 |
AUDIO ALARM ASM Price: $137.61 |
| 26 |
95-0659 |
MODULE - INTERLOCK Price: $156.68 |
| 27 |
83-2280 |
TIMER-DELAY Price: $126.04 |
| 28 |
2412-39 |
CLAMP-R Price: $1.70 |
| 29 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 31 |
3254-10 |
WASHER-LOCK/INT Price: $0.16 |
| 32 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 33 |
3217-16 |
NUT-HEX Price: $0.25 |
| 34 |
3255-20 |
WASHER-LOCK Price: $0.25 |
| 35 |
3217-25 |
NUT-HEX Price: $0.25 |
| 36 |
3254-20 |
WASHER-LOCK, INT This part replaces 218-589. Price: $1.29 |
| 37 |
218-588 |
SCREW Price: $0.25 |
| 38 |
3253-19 |
WASHER-LOCK Price: $0.25 |
