| Ref | Part Number | Description |
|---|
| 1 |
61-8300 |
ARM-PIVOT, FRONT Price: $27.99 |
| 2 |
49-8770 |
QUADRANT-FRONT, RH Price: $25.99 |
| 3 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 4 |
14-9499 |
HOUSING W/DECALS This part replaces 14-6149. Price: $929.99 |
| 5 |
32144-111 |
SCREW-PPH Price: $0.89 |
| 6 |
76-2130 |
KICKER Price: $24.99 |
| 7 |
39-5770 |
DECAL-DANGER Price: $7.99 |
| 8 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 9 |
82-9150 |
DISCHARGE TUNNEL Price: $125.66 |
| 10 |
71-9350 |
BRACKET-SPRING This part replaces 76-4560. Price: $13.99 |
| 11 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 12 |
76-4660 |
SPRING-DOOR Price: $10.99 |
| 13 |
80-3770 |
RETAINER-DOOR Price: $6.49 |
| 14 |
77-0200 |
DISCONTINUED Price: Call Us |
| 15 |
76-4570 |
DOOR LATCH PLATE Price: $5.27 |
| 16 |
46-8090 |
SCREW-PLASTITE Price: $2.04 |
| 17 |
321-7 |
SCREW-HH Price: $4.19 |
| 18 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 19 |
76-2150 |
KICKER Price: $24.99 |
| 20 |
71-1280 |
DECAL-INSTRUCTION, SAFETY Price: $24.51 |
| 21 |
77-0500 |
DISCHARGE PLUG ASM Price: $64.99 |
| 22 |
37-7260 |
SCREW-HWH Price: $5.09 |
| 23 |
63-9441 |
COVER-BELT Price: $49.99 |
| 24 |
52-2610 |
LABEL-GREASE, HP Price: $5.06 |
| 25 |
49-8740 |
QUADRANT-REAR, LH Price: $25.99 |
| 26 |
74-1810 |
WASHER Price: $0.39 |
| 27 |
49-8790 |
SHAFT-AXLE, REAR Price: $50.99 |
| 28 |
48-2170 |
CAP-END Price: $9.99 |
| 29 |
25-7740 |
KNOB-ARM Price: $4.59 |
| 30 |
66-7561 |
REAR SPRING ARM ASM Price: $18.99 |
| 31 |
42-3510 |
PIVOT ARM ASM Price: $49.99 |
| 32 |
302-56 |
FITTING-GREASE Price: $3.69 |
| 33 |
47-2900 |
BUSHING Price: $5.49 |
| 34 |
47-2890 |
BUSHING Price: $3.19 |
| 35 |
36-4780 |
WASHER-PLAIN Price: $6.59 |
| 36 |
32121-108 |
PIN-SPIROL Price: $6.09 |
| 37 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 38 |
33-3208 |
ROD-SHIELD Price: $13.99 |
| 39 |
112-9989 |
SHIELD-TRAILING This part replaces 44-0580. Price: $26.99 |
| 40 |
76-2140 |
KICKER Price: $24.99 |
| 41 |
66-7560 |
FRONT SPRING ARM ASM Price: $12.99 |
| 42 |
27-6231 |
WHEEL BOLT Price: $4.49 |
| 43 |
53-7740 |
TIRE Price: $37.99 |
| 44 |
52-2410 |
HUB-BEARING Price: $31.99 |
| 45 |
52-2440 |
SPACER-BEARING Price: $9.99 |
| 46 |
52-2450 |
BEARING-WHEEL Price: $17.99 |
| 47 |
121-1365-06 |
RIM-HALF, WHEEL This part replaces 53-7780. Price: $16.99 |
| 48 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 49 |
323-12 |
SCREW-HH Price: $1.14 |
| 50 |
52-2480 |
SPACER-WHEEL Price: $5.89 |
| 51 |
321-2 |
SCREW-HH Price: $2.79 |
| 52 |
257-3 |
WASHER-THRUST Price: $14.99 |
| 53 |
40-1940 |
WASHER Price: $1.59 |
| 54 |
32153-11 |
NUT-LOCK This part replaces 52-3620. Price: $3.99 |
| 55 |
49-8760 |
QUADRANT-FRONT, LH Price: $25.99 |
| 56 |
82-8190 |
DECAL - RECYCLER Price: $4.84 |
| 57 |
76-2120 |
KICKER Price: $24.99 |
