| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT This part replaces 92-1180. Price: $273.15 |
| 1 |
532448157 |
Price: Call Us |
| 2 |
92-6534 |
ORDER COMPLETE SEAT This part replaces 67-9560. Price: Call Us |
| 3 |
283-72 |
PIN-LYNCH Price: $9.12 |
| 4 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 5 |
83-6630 |
SHIM - SWITCH Price: $5.56 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
75-6330 |
DISCONTINUED Price: Call Us |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
83-6640 |
SENSOR - REED SWITCH Price: $223.35 |
| 9 |
83-6700 |
SUSPENSION PLATE WA *B Price: $178.89 |
| 10 |
85-6160 |
PIN SPRING Price: $34.80 |
| 11 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
32121-4 |
PIN-ROLL, SLOTTED Price: $3.49 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
27-4720 |
SHAFT-PIVOT, SEAT Price: $32.27 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
83-6690 |
SEAT PLATE WA *B Price: $237.12 |
| 16 |
85-6140 |
SPRING Price: $38.33 |
| 17 |
92-6533 |
SEAT CUSHION KIT This part replaces 92-1179. Price: $290.43 |
| 18 |
69-0770 |
BRACKET-ARM, RH Price: $117.82 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 19 |
69-1260 |
SPACER Price: $11.05 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 20 |
69-1180 |
ARMREST Price: $166.08 |
| 21 |
32128-19 |
NUT-HF Price: $0.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
323-9 |
SCREW-HH Price: $1.29 |
| 23 |
3234-14 |
SCREW-HHF This part replaces 3234-23. Price: $0.61 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 190 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
