| Ref | Part Number | Description |
|---|
| 1 |
110-4817 |
KIT - AXLE HOUSING This part replaces 95-7538. Price: $657.17 |
| 1 |
530015650 |
Screw This part replaces 530015871. Price: $1.99 |
| 2 |
104-2378 |
BUSHING Price: $40.73 |
| 2 |
115-0622 |
SEAL - OIL This part replaces 100-2557. Price: $10.23 |
| 2 |
530047382 |
Handguard (Type 1 only) Price: $7.99 |
| 3 |
530016154 |
Screw Price: $0.99 |
| 4 |
530037467 |
Assy-Switch Wire Price: $19.99 |
| 5 |
104-2376 |
KNUCKLE ASM Price: $68.43 |
| 5 |
530015895 |
Screw Price: $1.99 |
| 6 |
104-2374 |
BOLT Price: $6.33 |
| 6 |
530069700 |
Kit-Cylinder Shield Price: $14.99 |
| 7 |
100-3768 |
LH STEERING ARM ASM Price: $207.28 |
| 7 |
545199901 |
IGNITION MODULE This part replaces 530039143. Price: $22.99 |
| 8 |
100-3766 |
RH STEERING ARM ASM Price: $207.28 |
| 8 |
530403094 |
NUT HEX LOCK 10-24 This part replaces 534235901. Price: $1.99 |
| 9 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 10 |
530095646 |
Assy-Fuel Pick-up This part replaces 530047004. Price: $2.69 |
| 10 |
95-7547 |
SHIM 0.1 Price: $2.53 |
| 10 |
95-7548 |
SHIM 0.2 Price: $3.52 |
| 10 |
95-7549 |
SHIM 0.3 Price: $3.82 |
| 11 |
530069247 |
Kit - Line Carb / Purge Price: $3.69 |
| 11 |
99-7597 |
PIN-DOWEL Price: $3.74 |
| 12 |
104-2375 |
BOLT Price: $18.54 |
| 12 |
530037464 |
Grommet-Carb. Price: $1.99 |
| 13 |
530015814 |
Screw Price: $1.49 |
| 13 |
99-7599 |
BOLT Price: $3.17 |
| 14 |
530019251 |
Seal-Super Clean Price: $1.99 |
| 14 |
99-7525 |
STUD Price: $7.03 |
| 15 |
530014943 |
Assy-C'case&Cylinder Price: Call Us |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
530037652 |
Heat Insulator Price: $1.99 |
| 16 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 17 |
530056256 |
BACKPLATE MUFFLER This part replaces 530047801. Price: $8.99 |
| 18 |
106-1141 |
STEERING TIE ROD ASM This part replaces 100-3762. Price: $642.02 |
| 18 |
530019205 |
Gasket-Muffler Price: $1.99 |
| 19 |
530015899 |
Screw Price: $1.99 |
| 20 |
545057701 |
Filter-Air (Top) This part replaces 530036141. Price: $2.99 |
| 21 |
530015970 |
Screw Price: $1.99 |
| 22 |
530059738 |
Filter-Air (Bottom) This part replaces 530037478. Price: $7.99 |
| 23 |
530036792 |
Isolator Price: $4.99 |
| 24 |
545013503 |
CARBURETOR This part replaces 530071345. Price: $32.99 |
| 25 |
530019172 |
Gasket-Carburetor Price: $1.49 |
| 26 |
530037872 |
Plate-Carburetor Price: $1.99 |
| 27 |
530071654 |
Kit-Carb.-Adapter This part replaces 530037668. Price: $17.99 |
| 28 |
530053396 |
Adaptor-Carb. Price: $2.99 |
| 30 |
530037380 |
Ring-Piston Price: $2.99 |
| 31 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 33 |
530037728 |
Muffler Body Price: $5.99 |
| 34 |
530015902 |
Bolt Price: $1.99 |
| 35 |
530037813 |
Diffuser Price: $1.99 |
| 36 |
530036103 |
Spark Screen Price: Call Us |
| 37 |
530037249 |
Muffler Cover Price: $3.99 |
| 38 |
530016170 |
Muffler Bolt Price: $1.99 |
| 39 |
530032117 |
Piston Pin Bearing Price: $4.36 |
| 40 |
503920801 |
This part replaces 530029794. Price: $124.99 |
| 43 |
530015897 |
Screw Price: $1.99 |
