| Ref | Part Number | Description |
|---|
| 1 |
738-3062 |
DRIVE SHAFT Not Available Price: |
| 1 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 2 |
748-3001 |
ARM-COUPLING Not Available Price: |
| 2 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 3 |
722-3000 |
Disc, Flexible Coupling Price: $25.02 |
| 3 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 4 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
903-0204 |
DRIVE SHAFT FLANGE ASSEMBLY This part replaces 703-0204. Price: $35.89 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 6 |
941-3004 |
BALL BUSHING This part replaces 741-3004. Price: $44.91 |
| 7 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 8 |
756-3000 |
Pulley, Drive 4L, 3.25 OD Price: $58.09 |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 9 |
916-0115 |
SNAP RING FOR .625 DIA SHAFT Not Available This part replaces 716-0115. Price: |
| 10 |
66-8610 |
DISCONTINUED Price: Call Us |
| 10 |
914-0868 |
Woodruff Key, 3/16 x 3/4 This part replaces 714-0868. Price: $3.50 |
| 11 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 11 |
954-3000 |
V-BELT .5 x 32.87 This part replaces 754-3000. Price: $28.09 |
| 12 |
703-0011 |
ARM ASSEMBLY-CLUTCH Not Available Price: |
| 12 |
76-1910 |
DISCONTINUED Price: Call Us |
| 13 |
750-3001 |
Bushing, Clutch Arm Price: Call Us |
| 13 |
82-9060 |
DISCONTINUED Price: Call Us |
| 14 |
712-3004 |
Nut, Hex Flange Lock, 5/16-18 Price: $3.49 |
| 14 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 15 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 15 |
756-3001 |
IDLER PULLEY .377X3.0 Not Available Price: |
| 16 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 16 |
712-3005 |
Nut, Hex Flange Lock, 3/8-16 Price: $5.99 |
| 17 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 17 |
747-3003 |
CLUTCH ROD Not Available Price: |
| 18 |
732-3003 |
EXTENSION SPRING Not Available Price: |
| 18 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 19 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 19 |
747-3004 |
BELT GUARD Not Available Price: |
| 20 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 20 |
747-3005 |
BELT GUARD Not Available Price: |
| 21 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 21 |
719-3001 |
BRAKE ROD LEVER Not Available Price: |
| 22 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 23 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 23 |
920-3000 |
CONTROL KNOB Not Available This part replaces 720-3000. Price: |
| 24 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 24 |
756-3002 |
V-PULLEY Not Available Price: |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
716-0101 |
Ring, Snap, .75 Dia Price: $3.37 |
| 26 |
703-0013 |
Bracket, Transmission Mounting, RH Price: Call Us |
| 26 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 27 |
703-0014 |
BRACKET-TRANS MTG (LH) Not Available Price: |
| 27 |
93-3164 |
CAP Price: $11.64 |
| 28 |
93-3163 |
SPRING Price: $26.01 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 503200316 |
503200316 |
SCREW Price: $3.99 |
| 503216618 |
503216618 |
SCREW Price: $3.99 |
| 503216820 |
503216220 |
SCREW W/ LOCKING FLUID This part replaces 503216820. Price: $3.99 |
| 503217725 |
503217725 |
SCREW Price: $2.99 |
| 503858901 |
503858901 |
STARTER ROPE Price: $8.99 |
| 503859001 |
503859001 |
SPRING Price: $12.99 |
| 503873305 |
503873305 |
STARTER PAWL BRIDGE Price: $22.99 |
| 503873502 |
544011401 |
STARTER PAWL This part replaces 503873502. Price: $9.99 |
| 503873601 |
503873601 |
SPRING Price: $3.99 |
| 537008401 |
537008401 |
STARTER HANDLE Price: $9.99 |
| 537034101 |
537034101 |
PLATE Price: $17.99 |
| 537353404 |
537353404 |
DECAL Price: $2.99 |
| 537353407 |
537353407 |
DECAL STARTER HOUSING Price: $3.99 |
| 537353431 |
537353431 |
DECAL Price: $2.99 |
| 537353432 |
537353432 |
DECAL DEVICE Price: $3.99 |
| 537353433 |
537353433 |
DECAL DEVICE Price: $3.99 |
| 537353434 |
537353434 |
DECAL, STARTER HOUSING Price: $0.99 |
| 537379302 |
537379302 |
SPACING SLEEVE Price: $4.99 |
| 537411601 |
537411602 |
STARTER HOUSING This part replaces 537411601. Price: $22.99 |
| 544038601 |
544038601 |
STARTER PULLEY Price: $5.99 |
| 544038702 |
579366201 |
PULLEY STARTER DRIVE This part replaces 544038702. Price: $5.99 |
| 544038802 |
544038802 |
SPRING - DRIVER Price: $5.99 |
| 544071102 |
544071103 |
STARTER ASSY This part replaces 544071102. Price: $54.99 |
| 544166501 |
544166501 |
STARTER PULLEY Price: $17.99 |
| 735310820 |
735310820 |
E-RING 4 Price: $2.99 |
