| Ref | Part Number | Description |
|---|
| 1 |
94-3622 |
HOOD ASM Price: $1,217.09 |
| 2 |
62-7400 |
DECAL Price: $24.54 |
| 3 |
32128-20 |
NUT-HF Price: $0.99 |
| 3 |
603000166 |
BELLOWS, LONG Price: $49.99 |
| 4 |
3230-27 |
SCREW-CARR Price: $0.75 |
| 5 |
603000168 |
RACK SCREW LOCKNUT Price: $11.99 |
| 5 |
76-2260 |
PAD-FOOTREST Price: $8.40 |
| 6 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 6 |
603000169 |
SNAP RING Price: $9.99 |
| 7 |
603000170 |
SEAL, STEERING PINION DUST Price: $11.99 |
| 7 |
76-2200-03 |
FOOTREST-PEDAL, TRACTION This part replaces 76-2200. Price: $42.73 |
| 8 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 8 |
603000549 |
BEARING BALL Price: $19.99 |
| 9 |
603000550 |
SUPPORT YOKE Price: $29.99 |
| 9 |
93-6779-03 |
FOOTREST-RH This part replaces 93-6779. Price: $85.60 |
| 10 |
32128-33 |
NUT-HF Price: $0.25 |
| 10 |
603000551 |
RACK GUIDE PRESSURE SPRING Price: $27.99 |
| 11 |
603000552 |
C-TYPE STOP RING Price: $17.99 |
| 11 |
93-6778-01 |
FENDER-RH This part replaces 93-6778. Price: $334.53 |
| 12 |
32128-44 |
NUT Price: $2.69 |
| 12 |
603000553 |
INNER BALL JOINT ASM Price: $89.99 |
| 14 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 15 |
32104-82 |
SCREW-HHF Price: $0.95 |
| 16 |
93-6858-01 |
SHIELD-FRONT, RH This part replaces 93-6858. Price: $23.11 |
| 17 |
93-6780-03 |
HINGE ASM This part replaces 93-6780. Price: $51.74 |
| 18 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 18 |
603002963 |
TIE WRAP, 8" NYLON Price: $1.99 |
| 19 |
256-320 |
BUSHING-NYLON Price: $7.44 |
| 19 |
603000682 |
TIE ROD END Price: $54.99 |
| 20 |
603000684 |
LOCKNUT, M12-1.25 NYLON Price: $3.99 |
| 20 |
93-6742-03 |
BRACKET-HOOD, PIVOT This part replaces 93-6742. Price: $12.30 |
| 21 |
3217-6 |
NUT-HEX Price: $1.19 |
| 21 |
603001603 |
BOLT Price: $3.99 |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 23 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 24 |
83-8510-01 |
BRACKET-FENDER, LEFT This part replaces 83-8510. Price: $24.64 |
| 25 |
83-9800-01 |
GRASS SHIELD-FRONT, LH This part replaces 83-9800. Price: $28.36 |
| 26 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 27 |
93-6776-01 |
FENDER-LH This part replaces 93-6776. Price: $317.84 |
| 28 |
93-7267 |
DECAL-BRAKE Price: $6.37 |
| 29 |
83-9710-03 |
FOOTREST-PEDAL, TRACTION This part replaces 83-9710. Price: $78.54 |
| 30 |
83-9840 |
PAD-FOOT Price: $60.60 |
| 31 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
93-6927 |
DISCONTINUED Price: Call Us |
| 33 |
3234-17 |
SCREW-HHF Price: $0.72 |
