| Ref | Part Number | Description |
|---|
| 1 |
353-536 |
DISCONTINUED Price: Call Us |
| 2 |
43-5350 |
GAS TANK Price: $388.80 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
109-0308 |
HOSE-FUEL This part replaces 37-9920. Price: $10.99 |
| 4 |
353-705 |
DISCONTINUED Price: Call Us |
| 5 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 6 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 7 |
55-3574 |
GAS CAP ASM Price: $15.94 |
| 8 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
3256-41 |
WASHER Price: $1.18 |
| 11 |
110-4104 |
HOSE-FUEL This part replaces 61-9650. Price: $8.95 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 12 |
231-103 |
TIRE(20X8-10) 4-PLY Price: $86.26 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
217-107 |
WHEEL ASM Price: $178.78 |
| 14 |
242-35 |
NUT-WHEEL Price: $9.04 |
| 15 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 15 |
583507201 |
TANK.ASSY.XTERNAL.FILL.GT2.TEX This part replaces 532435816. Price: $129.99 |
| 16 |
86-9660-03 |
AXLE ASM This part replaces 86-9660. Price: $3,635.80 |
| 17 |
3217-8 |
NUT-HEX Price: $1.34 |
| 18 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 18 |
532441462 |
CAP.ASM.FUEL.2.25"TOP.TURN Price: $11.99 |
| 19 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 20 |
324-9 |
SCREW-HH Price: $1.76 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 21 |
110-3258 |
HOSE-FUEL This part replaces 71-3370. Price: $23.35 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
92-6312 |
DISCONTINUED Price: Call Us |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 70 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 Price: $24.99 |
| 71 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 Price: $24.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 137 |
532441461 |
SPILL.CUP Price: $7.99 |
