| Ref | Part Number | Description |
|---|
| 1 |
117-0959 |
ROLLER-WIEHLE, PLASTIC Price: $366.77 |
| 1 |
545008010 |
STARTER SPRING This part replaces 530029395. Price: $3.99 |
| 2 |
117-0957 |
SHAFT-ROLLER, WIEHLE Price: $105.15 |
| 2 |
530015775 |
Screw-Lead Wire Price: $1.99 |
| 3 |
530027523 |
Retainer Price: $2.99 |
| 4 |
530015934 |
Screw-Shrd/Fan Hsg. Price: $1.99 |
| 5 |
530027569 |
Starter Handle Price: $1.99 |
| 6 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
530019233 |
Gasket - Cylin./Carb. This part replaces 530019185. Price: $1.99 |
| 8 |
530030075 |
Spark Plug (RCJ-8Y) Price: Call Us |
| 9 |
530019194 |
Gasket-Carb. Price: $1.99 |
| 10 |
530015945 |
Retaining Ring C'case Price: $1.99 |
| 11 |
530029606 |
Lead Wire Price: $0.81 |
| 12 |
530037321 |
Switch Wire Form Price: $0.86 |
| 13 |
545221701 |
FLYWHEEL ASSY This part replaces 530039149. Price: $8.99 |
| 14 |
530039163 |
Ignition Module Price: $34.99 |
| 15 |
530036145 |
Spacer-Ignition Mod. Price: $1.99 |
| 16 |
530015954 |
Screw-Ignition Mod. Price: $1.99 |
| 17 |
530015149 |
Washer-Flywheel Price: $1.99 |
| 18 |
530037705 |
Spacer-Flywheel Price: $5.99 |
| 19 |
530037319 |
Crankshaft Ass'y. Price: Call Us |
| 20 |
530069615 |
Connecting Rod Ass'y. Price: $14.99 |
| 21 |
530036404 |
Piston Ring Price: $4.99 |
| 22 |
530014861 |
Crankcase Ass'y. (Incl. 23-26) Price: $37.77 |
| 23 |
530032125 |
Inner Bearing Price: $11.99 |
| 24 |
530032124 |
Outer Bearing Price: $4.99 |
| 25 |
530019179 |
C'case Seal Price: $2.99 |
| 26 |
530015941 |
Retain Ring-C'shaft Price: $1.99 |
| 27 |
530036578 |
Muffler Body Price: $2.99 |
| 28 |
530036577 |
Muffler Cover Price: $2.99 |
| 29 |
530038602 |
Muffler Baffle-Exit Price: $1.99 |
| 30 |
530036579 |
Muffler Baffle-First Price: $2.99 |
| 31 |
530016197 |
Muffler Spring This part replaces 530029930. Price: $1.99 |
| 32 |
530047091 |
Shroud & Tank Assy. Price: $13.04 |
| 33 |
530019181 |
Gasket-C'case Price: $1.99 |
| 34 |
530069618 |
Cylinder Price: $89.99 |
| 35 |
530038476 |
Carb. Adaptor Price: $4.99 |
| 36 |
530016014 |
Screw-Carb. Adap. Price: $1.99 |
| 37 |
530019223 |
Gasket-Cylinder Price: $1.99 |
| 38 |
530071639 |
Carburetor Assembly - WT-639 This part replaces 530069683. Price: $54.99 |
| 39 |
530037971 |
Air Box Price: $3.99 |
| 40 |
530037326 |
Choke Plate Price: $1.99 |
| 41 |
530038102 |
Choke Shutter Price: $1.99 |
| 42 |
530015254 |
Wave Washer Price: $1.99 |
| 43 |
530015852 |
Choke Spacer Price: $1.99 |
| 44 |
530015849 |
Screw-Carb. Price: $1.99 |
| 45 |
530037413 |
Filter Plate Price: $1.99 |
| 46 |
530037331 |
Air Filter Foam Price: $1.99 |
| 47 |
530037292 |
Air Filter Cover Price: $1.99 |
| 48 |
530015957 |
Screw This part replaces 530015966. Price: $1.99 |
| 49 |
530037415 |
Throttle Cable Ass'y. Price: $4.99 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
| 50 |
530015814 |
Screw-Throttle Cab. Price: $1.99 |
| 51 |
530026119 |
Check Valve Price: $1.99 |
| 52 |
530029717 |
Element Price: $1.24 |
| 53 |
530029696 |
Retainer Price: Call Us |
| 54 |
530069247 |
Fuel Line-Tnk/Carb. Price: $3.99 |
| 55 |
530014347 |
Fuel Cap Ass'y. Price: $4.99 |
| 56 |
530095646 |
Assy-Fuel Pickup This part replaces 530014362. Price: $2.99 |
| 57 |
530069388 |
Engine Gasket Kit (Incl. 7, 9, 33, 37) Price: $2.99 |
| 58 |
530071625 |
C'case & C'shaft Ass'y. This part replaces 530014906. Price: $39.99 |
| 59 |
530038309 |
Switch Button Price: $1.99 |
| 60 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 61 |
530016072 |
Screw-Pinch Clamp Price: $1.99 |
| 62 |
530015768 |
Locknut-Pinch Clmp Price: $1.99 |
| 63 |
530047017 |
Fan Housing Price: $17.99 |
| 64 |
530069232 |
Rope Kit Price: $3.99 |
| 65 |
530016080 |
Screw-Rope Retain. Price: $1.99 |
| 66 |
530071786 |
STARTER PULLEY KIT This part replaces 530069400. Price: $3.99 |
| 67 |
530069380 |
Spark Arrestor Kit Price: $3.99 |
| 68 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 69 |
530069620 |
Piston Kit (Incl. 21,68, & Pin) Price: $24.99 |
| 70 |
530069660 |
Muffler Kit This part replaces 530069389. Price: $11.99 |
| 71 |
530015611 |
Washer-Clutch Price: $1.99 |
| 72 |
530069491 |
Clutch Ass'y. Price: $7.99 |
| 73 |
530015828 |
Washer-Clutch Price: $1.99 |
| 74 |
530626605 |
Nut-Clutch Price: $1.99 |
| 75 |
530014924 |
Clutch Hsg. Price: $27.99 |
| 76 |
530015886 |
Screw-Clutch Hsg. Price: $1.99 |
| 77 |
530029939 |
Starter Dog Price: Call Us |
| 78 |
530047570 |
Spring - Starter Dog This part replaces 530037730. Price: $1.99 |
| 79 |
530038874 |
Primer Bulb Ass'y. Price: $5.99 |
| 80 |
530015780 |
Screw-Type II This part replaces 530016090. Price: $1.99 |
| 81 |
530069571 |
Fuel Line-Prim./Tnk. Price: $2.99 |
| 82 |
530069216 |
Fuel Line-Carb/Prim. Price: $3.99 |
| 83 |
530015882 |
Screw-Flywheel Price: $1.99 |
| 530083797 |
Operator |
Manual Price: $3.33 530083797 |
