| Ref | Part Number | Description |
|---|
| 1 |
112-1479 |
SKID-BUMPER, DECK Price: $95.09 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144925. Price: $139.99 |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
68-6710 |
ROLLER Price: $59.98 |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 5 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 6 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 119-4776. Price: $589.65 |
| 8 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
532414126 |
TRAY.ASM.BATTERY.FRT.TEX.CARB Price: $27.99 |
| 10 |
3231-33 |
SCREW-CARR Price: $4.29 |
| 11 |
3269-24 |
RIVET Price: $1.79 |
| 12 |
9136144 |
SCREW-HWHTF Price: $6.29 |
| 13 |
120-6647 |
DECK ASM Price: $5,589.17 |
| 14 |
108-1908 |
SPACER-IDLER Price: $23.93 |
| 15 |
3233-34 |
SCREW-CARR Price: $7.98 |
| 16 |
107-4738 |
BELT-HH Price: $164.47 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
107-4725 |
PULLEY Price: $274.56 |
| 18 |
140-5847 |
PULLEY-IDLER This part replaces 01-268-0160. Price: $98.46 |
| 19 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 20 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 21 |
108-1926 |
WASHER Price: $5.30 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
108-1921 |
SPRING-TORSION Price: $28.33 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 23 |
140-7078 |
IDLER ARM ASM This part replaces 108-1930. Price: $49.85 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 Price: $4.99 |
| 25 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 Price: $4.99 |
| 26 |
3296-45 |
NUT-HEX Price: $3.79 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
108-1924 |
SPACER-IDLER Price: $11.13 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
108-1993 |
SCREW-HSBH Price: $3.66 |
| 28 |
532416588 |
CABLE.GROUND.21"BLK.8GA.90T Price: $5.99 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
108-1914 |
PAD-BUMPER Price: $11.14 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411933 |
KEY.CHAIN.BLISTER.PACK.GEN.USA Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $74.99 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $2.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT Price: $5.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 100 |
819091416 |
WASHER Price: $3.99 |
| 102 |
581023401 |
HARNESS.PIGTAIL.VARIATOR.SD Price: $12.99 |
