| Ref | Part Number | Description |
|---|
| 1 |
110-8785 |
HYD MOTOR ASM (CCW) Price: $1,062.27 |
| 2 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 3 |
110-8786 |
HYD MOTOR ASM (CW) Price: $1,062.27 |
| 4 |
322-9 |
SCREW-HH Price: $3.09 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
56-7971 |
CLAMP-TUBE Price: $17.90 |
| 8 |
95-8783 |
TUBE ASM Price: $172.34 |
| 9 |
353-990 |
PLUG ASM Price: $10.01 |
| 11 |
95-8784 |
TUBE ASM Price: $181.92 |
| 12 |
3274-99 |
SCREW-HSH Price: $3.04 |
| 13 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000-03. Price: $8.08 |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 14 |
532441267 |
HOOD.HUSQVARNA.LT.ORANGE Price: $79.99 |
| 15 |
532406664 |
LENS.HUSQVARNA LT.LH This part replaces 532441428. Price: $14.99 |
| 18 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 20 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 21 |
321-5 |
SCREW-HH Price: $0.22 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 23 |
104-7705 |
BRAKE ASM Price: $175.69 |
| 24 |
104-0485-0P |
SHIELD - WHEEL This part replaces 104-0485-03. Price: $38.89 |
| 25 |
119-8238 |
SPACER-DECK PULLEY Price: $7.49 |
| 25 |
532406663 |
LENS.HUSQVARNA LT.RH This part replaces 532441427. Price: $14.99 |
| 26 |
114-2726 |
LEVER-BRAKE Price: $29.20 |
| 28 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 30 |
115-6672 |
BRAKE LEVER ASM Price: $22.20 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 33 |
104-4625-03 |
SHAFT-PIVOT, BRAKE Price: $158.63 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS Price: $59.99 |
| 34 |
95-8683 |
BRACKET-PIVOT, BRAKE Price: $13.75 |
| 35 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 37 |
597652401 |
SERVICE KIT FENDER.TLT.CPH.615 This part replaces 532441206. Price: $219.99 |
| 38 |
104-7706 |
E-RING, BOWED Price: $1.72 |
| 39 |
3274-105 |
SCREW-HSBH Price: $7.79 |
| 40 |
104-4809 |
DRUM-BRAKE Price: $58.92 |
| 41 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 52 |
596040501 |
Hardware Price: $2.99 |
| 58 |
531152601 |
SERVICE KIT DRAWBAR FENDER DRA This part replaces 532412280. Price: $44.99 |
| 68 |
596030701 |
Screws Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY Price: $4.99 |
| 150 |
532406662 |
AIR DUCT Price: $24.99 |
| 151 |
532407807 |
BRACKET PIVOT Price: $27.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 175 |
532199472 |
CROSSMEMBER Price: $24.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195228 |
BUSHING STEERING Price: $4.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. This part replaces 532439746. Price: $4.99 |
| 182 |
532407176 |
DASH.LOWER.PREDATOR LT Price: $69.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 191 |
583358401 |
INSERT.REFLECTIVE.RH. This part replaces 532416501. Price: $11.99 |
| 196 |
547634701 |
CONSOLE.DECKLIFT.GREY.PKG.KIT This part replaces 532439647. Price: $17.99 |
| 202 |
532441342 |
VENT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 203 |
532406671 |
VENT SIDE HOOD This part replaces 532441343. Price: $8.99 |
| 204 |
532441375 |
SUBASM.TOP.VENT.HUSQ.LT Price: $17.99 |
| 205 |
532441344 |
SKIRT.SIDE.HUSQVARNA.LT.RT Price: $11.99 |
| 206 |
532441345 |
SKIRT.SIDE.HUSQVARNA.LT.LEFT Price: $11.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532407881 |
TRIM.HUSQ LT.668 This part replaces 532441374. Price: $19.99 |
| 239 |
532404883 |
IS ITO Price: $5.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 297 |
532406665 |
INSERT REFLECTIVE Price: $6.99 |
