| Ref | Part Number | Description |
|---|
| 1 |
353433 |
Straight Fitting Price: Call Us |
| 1 |
587834801 |
DECK.SVC.54" Price: $449.99 |
| 2 |
237-80 |
O-RING Price: $6.10 |
| 3 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 4 |
39-3790 |
DISCONTINUED Price: Call Us |
| 5 |
282-2 |
YOKE Price: $30.04 |
| 6 |
32724 |
Cotter Pin Price: Call Us |
| 6 |
532196066 |
COVER.MANDREL.LH.54"20 Price: $19.99 |
| 7 |
283-26 |
PIN Price: $3.73 |
| 7 |
532197181 |
COVER.MANDREL.RH.54.20 Price: $29.99 |
| 8 |
29-1070 |
LEVER ASM Price: $64.17 |
| 9 |
29-1060 |
BRACKET-SECONDARY Price: $135.49 |
| 9 |
583970702 |
TORQUE STRAP PNT BLACK Price: $8.99 |
| 10 |
323-14 |
SCREW-HH Price: $1.34 |
| 11 |
29-1080 |
BRAKE PAD Price: $66.87 |
| 11 |
581101101 |
BLADE.BAGGER.54" Price: $19.99 |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 12 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $17.99 |
| 13 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 13 |
587126105 |
MANDREL.INT.SPACER.NONGRS.RE This part replaces 580862101. Price: $32.99 |
| 14 |
38-3360 |
DISCONTINUED Price: Call Us |
| 14 |
581204301 |
HOUSING.MANDREL.REV.TALL.GRSBL Price: $27.99 |
| 15 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 15 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $7.99 |
| 16 |
217-74 |
BOLT-WHEEL Price: $4.87 |
| 16 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 17 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 17 |
99-3139 |
NUT This part replaces 11-5800. Price: $16.11 |
| 18 |
29-1020 |
FRT WHEEL HUB *BO Price: $310.00 |
| 18 |
872140505 |
BOLT Price: $2.99 |
| 19 |
29-1040 |
DISCONTINUED Price: Call Us |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $1.99 |
| 20 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 21 |
32534 |
Lockwasher Price: Call Us |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 22 |
322-3 |
SCREW-HH Price: $0.79 |
| 23 |
325-7 |
SCREW-HH Price: $1.53 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 24 |
56-6800 |
DISCONTINUED This part replaces 36-5610. Price: Call Us |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $1.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $54.99 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
873680600 |
LOCKNUT Price: $1.99 |
| 35 |
584309301 |
SCREW.SEMS.7/16-20X1.HEX.HEAD Price: $1.99 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATIONARY.LH This part replaces 532197380. Price: $22.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $1.99 |
| 43 |
532196065 |
ARM.IDLER Price: $11.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 Price: $44.99 |
| 49 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 50 |
872110616 |
BOLT Price: $3.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 58 |
532187342 |
BAFFLE.RIGHT.54" Price: $12.99 |
| 59 |
532187344 |
BAFFLE.LEFT.54" Price: $14.99 |
| 60 |
532187607 |
BAFFLE CENTER 54" MOWER Price: $17.99 |
| 61 |
585322605 |
PLATE.REIN.FRONT.BOLT54"X431 Price: $5.99 |
| 62 |
585322805 |
PLATE.REIN.SIDE.BOLT.54"X431 Price: $8.99 |
| 63 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $3.99 |
| 65 |
580954003 |
HOLDER.BLADE.REVOLUTION Price: $139.99 |
| 97 |
532178515 |
WASHER Price: $2.99 |
| 98 |
532196105 |
SPRING, DECK DRIVE Price: $4.99 |
| 113 |
872110508 |
BOLT CRT Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $12.99 |
| 116 |
532193406 |
BOLT.SHOULDER.3/8-16X3-5/8. Price: $1.99 |
| 117 |
532174873 |
WHEEL. GUAGE RALLY Price: $7.99 |
| 120 |
819132012 |
WASHER Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $2.99 |
| 184 |
739005000 |
Price: Call Us |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
532195185 |
ARM.SUSPENSION.MOWER Price: $11.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $5.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X Price: $8.99 |
| 196 |
872140620 |
BOLT Price: $3.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 245 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 246 |
586638501 |
CAP.REVOLUTION ASM Price: $9.99 |
