| Ref | Part Number | Description |
|---|
| A |
530029159 |
Shaft Warning Decal Price: $0.85 |
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
530029445 |
Grip Price: $2.99 |
| 2 |
530015768 |
Nut Price: $1.99 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
530071371 |
ASM-DR.SHAFT W/SHIELD This part replaces 530094891. Price: $43.11 |
| 4 |
106-5363 |
SHAFT-ADJUSTER Price: $41.05 |
| 4 |
530010957 |
Handle Ass'y. Price: Call Us |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
530015197 |
Nut Price: $1.99 |
| 6 |
114-9396 |
CAPSCREW-HH Price: $2.22 |
| 6 |
530015774 |
Screw Price: $1.99 |
| 7 |
530010959 |
Throttle Housing Ass'y. Price: $6.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
119-4164 |
WASHER-WAVE This part replaces 106-5335. Price: $2.73 |
| 8 |
530069347 |
HANDLE KIT This part replaces 530069252. Price: $4.99 |
| 9 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 9 |
530069249 |
Shield Kit Ass'y. (Inc. 10,11,12,14) Price: $9.99 |
| 10 |
137-6132 |
SCREW-ADJUSTER, BEDBAR This part replaces 99-2096. Price: $32.54 |
| 10 |
530015337 |
Screw Price: $1.99 |
| 11 |
530094883 |
Line Limiter Price: $3.33 |
| 11 |
99-2098 |
WASHER Price: $7.01 |
| 12 |
119-4156 |
SPRING-COMPRESSION This part replaces 99-3755. Price: $0.91 |
| 12 |
530403094 |
Nut This part replaces 534235901. Price: $1.99 |
| 13 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 13 |
530093653 |
Shield Bracket Price: $1.99 |
| 14 |
530016107 |
Screw Price: $1.99 |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
530094543 |
Dust Cup Price: $1.99 |
| 16 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 16 |
530094551 |
Drive Shaft Price: $12.99 |
| 17 |
137-6094 |
BEDKNIFE-EDGEMAX (RM 22IN) This part replaces 108-9095. Price: $166.88 |
| 17 |
530031159 |
Hex Wrench (5/32) This part replaces 530031111. Price: $1.99 |
| 19 |
952701605 |
SensorFeed Price: Call Us |
| 19 |
952711547 |
Cutting Head Ass'y. This part replaces 952701574. Price: $19.95 |
| 20 |
530071295 |
Hub This part replaces 530093896. Price: $14.99 |
| 20 |
530094592 |
SensorFeed Price: Call Us |
| 20 |
530094841 |
TNG II Price: $11.99 |
| 21 |
530094956 |
Spring Price: $0.99 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
530069312 |
Plate Price: $3.99 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 23 |
530015542 |
Screw Price: Call Us |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 24 |
952701523 |
TNG I Price: $5.95 |
| 24 |
952701606 |
TNG II Price: $9.75 |
| 24 |
952701607 |
SensorFeed Price: Call Us |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 25 |
530094522 |
TNG II Price: $2.81 |
| 25 |
530401183 |
TNG I Price: $2.99 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 26 |
530092133 |
TNG I Price: $5.99 |
| 26 |
530094494 |
SensorFeed Price: $4.99 |
| 26 |
530094521 |
TNG II Price: $7.99 |
| 27 |
108-4269-01 |
WEIGHT Price: $146.07 |
| 27 |
530014222 |
Handle Price: $5.99 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 28 |
530015610 |
Nut Price: $0.99 |
| 29 |
530094742 |
Clamp Price: $2.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 30 |
530093898 |
Line Saver Price: $3.99 |
| 31 |
530340007 |
Spring Price: $1.99 |
| 32 |
137-8433 |
REEL+,7IN FWY(22)11 BLD This part replaces 117-0980. Price: $671.21 |
| 32 |
530328929 |
Cap Spring This part replaces 530092068. Price: $1.99 |
| 33 |
530093897 |
Drive Gear Price: $6.99 |
