| Ref | Part Number | Description |
|---|
| 1 |
04969759 |
WMT-FENDER-RH Price: $145.95 |
| 1 |
27-7200 |
AIR CLEANER HOSE Price: $90.31 |
| 2 |
04969859 |
WMT-FENDER-LH Price: $145.95 |
| 2 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 3 |
27-7180 |
CAP Price: $70.51 |
| 3 |
51703800 |
CHASSIS-SPLITTER W/SFTY DECALS Price: $499.95 |
| 4 |
00463000 |
BREATHER, DIPSTICK Price: $32.95 |
| 4 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 5 |
03857000 |
AXLE, SPLITTER Price: $68.45 |
| 5 |
44-8950-03 |
AIR CLEANER TUBE This part replaces 44-8950. Price: $53.15 |
| 6 |
03857500 |
LOCK, BEAM Price: $13.45 |
| 6 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 7 |
04852351 |
PIN, .373 X 7.30 X 2X.109 THRU Price: $22.95 |
| 7 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 8 |
05901806 |
BLT, HEX .31-18X2.25 G5 ZCC This part replaces 05963700. Price: $1.45 |
| 8 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 9 |
06200232 |
BLT,RHSN .31-18X.75 G5 ZCC This part replaces 06215700. Price: $2.45 |
| 9 |
3258-19 |
SCREW Price: $0.42 |
| 10 |
06401012 |
WSHR,FLT .563X1.375X.109 ZCC This part replaces 06442000. Price: $2.45 |
| 10 |
322-3 |
SCREW-HH Price: $0.79 |
| 11 |
06513100 |
NUT-SL 1.0-14 Price: $5.45 |
| 11 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 12 |
06500826 |
NUT,LK-CTR .31-18 GA ZCC This part replaces 06529800. Price: $1.45 |
| 12 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 13 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 13 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 14 |
06700215 |
PIN, HAIR-#7 .094X2.31 ZC120 This part replaces 06712900. Price: $5.95 |
| 14 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 15 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 16 |
06700223 |
PIN, HAIR #225 .072X1.09 This part replaces 06714800. Price: $0.45 |
| 16 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 17 |
06944800 |
CLIP, SPRING Price: $0.95 |
| 17 |
32534 |
Lockwasher Price: Call Us |
| 18 |
07101210 |
ASM,TIRE/WHEEL 4.8/4-8 P47GRAY Price: $109.95 |
| 18 |
3217-6 |
NUT-HEX Price: $1.19 |
| 19 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 21 |
08325900 |
SPRG, COMP .058X.65X2.13 WLD15 Price: $7.95 |
| 22 |
51700400 |
REAR STAND W/DECALS (ARIENS) Price: $85.95 |
