| Ref | Part Number | Description |
|---|
| 1 |
532150546 |
STEERING WHEEL NLA This part replaces 532126805. Price: $55.99 |
| 1 |
92-9727 |
HOC CAP ASM Price: $78.05 |
| 2 |
127-3741 |
CASTOR ARM ASM KIT This part replaces 100-8093. Price: $311.96 |
| 2 |
873940800 |
Nut, Hex, Toplock Jam 1/2-20 Price: $3.99 |
| 3 |
532100712 |
Washer 17/32 x 2-1/4 x .160 Price: $2.42 |
| 3 |
69-6860 |
WASHER-THRUST Price: $3.15 |
| 4 |
532150546 |
STEERING WHEEL NLA This part replaces 532121472. Price: $55.99 |
| 4 |
69-1510 |
SPACER Price: $4.48 |
| 5 |
140-6306-01 |
CASTER FORK ASM This part replaces 104-0762-01. Price: $241.08 |
| 5 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532100711. Price: $19.99 |
| 6 |
327-24 |
SCREW-HH Price: $7.99 |
| 6 |
812000029 |
Ring, Klip Price: $1.99 |
| 7 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 7 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Gauge Price: $1.99 |
| 8 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 8 |
532009040 |
Bearing, Flange This part replaces 532124959. Price: $3.99 |
| 9 |
3234-41 |
SCREW-HHF Price: $0.31 |
| 9 |
532122073 |
TIRE.FRONT (15X6-6) TURF SAVER This part replaces 532106222. Price: $45.99 |
| 10 |
532059904 |
Tube, Tire Price: $22.69 |
| 10 |
93-9938 |
WHEEL ASM Price: $144.61 |
| 12 |
532065139 |
Stem, Valve Price: $5.99 |
| 13 |
532059192 |
Cap, Valve Price: $3.99 |
| 14 |
532108075 |
Axle Assembly, Front Price: $62.55 |
| 15 |
874761060 |
Bolt, Hex 5/8-11 x 3-3/4 Price: $3.99 |
| 16 |
532130524 |
SPINDLE This part replaces 532105654. Price: $29.99 |
| 17 |
873610500 |
NUT This part replaces 873810500. Price: Call Us |
| 18 |
819272016 |
Washer 27/32 x 1-1/4 x 16 Gauge Price: $2.99 |
| 19 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532121334. Price: $59.99 |
| 20 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 21 |
539990118 |
WASHER.3/8 This part replaces 810040600. Price: $1.49 |
| 22 |
873680600 |
Nut This part replaces 873610600. Price: $1.99 |
| 23 |
532130468 |
Link Drag Sol Ball Jt 20 064 This part replaces 532124032. Price: $45.99 |
| 24 |
532156544 |
This part replaces 532124043. Price: $61.99 |
| 25 |
532057079 |
Washer Price: $2.99 |
| 26 |
532160395 |
SUPPORT SHAFT This part replaces 532124035. Price: $6.99 |
| 27 |
532124036 |
Bracket, Steering Price: $4.99 |
| 28 |
532136874 |
Gear Sector This part replaces 532124034. Price: $45.99 |
| 29 |
532165857 |
SCREW This part replaces 871070410. Price: $2.99 |
| 30 |
819091016 |
Washer 9/32 x 5/8 x 16 Ga This part replaces 532126684. Price: $2.99 |
| 31 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 32 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 33 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532124033. Price: $26.99 |
| 34 |
532105656 |
Spindle Assembly, L.H. Price: $39.99 |
| 35 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 This part replaces 817490612. Price: $3.99 |
| 36 |
873681000 |
Nut, Crownlock This part replaces 873601000. Price: $3.99 |
| 37 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $1.99 |
| 39 |
532104757 |
Cover, Wheel, Front Price: $1.99 |
| 40 |
532000278 |
Fitting, Grease This part replaces 532124957. Price: $2.99 |
| 41 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Gauge Price: $1.99 |
| 44 |
532105664 |
Support, Saddle, Front Price: $9.99 |
| 45 |
532105663 |
Support, Saddle, Rear Price: $8.25 |
| 46 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 47 |
810040500 |
Washer, Lock 5/16 Price: $2.99 |
| 48 |
532122819 |
Screw, Special Price: $2.38 |
| 49 |
532109816 |
Nyliner, Snap In Price: $2.99 |
| 50 |
532124037 |
Gear, Pinion Price: $4.99 |
| 51 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.02 |
| 52 |
532121232 |
Cap, Spindle Price: $1.99 |
| 53 |
532183226 |
Fitting, Grease This part replaces 532124836. Price: $3.99 |
