| Ref | Part Number | Description |
|---|
| 1 |
121-8177 |
PULLEY-SINGLE Price: $314.36 |
| 2 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 3 |
33115-035 |
SCREW-HH Price: $1.15 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H Price: $5.99 |
| 4 |
110-6254 |
BELT-V Price: $35.99 |
| 5 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 5 |
532408703 |
DASH Price: $54.99 |
| 6 |
3231-5 |
SCREW-CARR Price: $1.39 |
| 7 |
127-3727-0P |
MOUNT-PULLEY This part replaces 127-3727-03. Price: $19.16 |
| 8 |
98-3095 |
PULLEY-IDLER Price: $111.99 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
127-3726-0P |
COMPRESSOR MOUNT ASM This part replaces 127-3726-03. Price: $185.43 |
| 11 |
33115-110 |
SCREW-HH Price: $2.92 |
| 12 |
119-0103 |
COMPRESSOR Price: $1,361.16 |
| 13 |
33095-00 |
WASHER-FLAT Price: $0.25 |
| 14 |
48-7960 |
NUT This part replaces 33015-00. Price: $1.40 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
117-2780 |
O-RING Price: $3.33 |
| 16 |
119-0128 |
FITTING-ELBOW, 90 DEG Price: $41.31 |
| 17 |
115-8882 |
CONDUIT-CONVOLUTED Price: $1.69 |
| 18 |
117-9410 |
FITTING-STRAIGHT Price: $15.83 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
597652401 |
SERVICE KIT FENDER.TLT.CPH.615 This part replaces 532441206. Price: $219.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
531152601 |
SERVICE KIT DRAWBAR FENDER DRA This part replaces 532412280. Price: $44.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
547634701 |
CONSOLE.DECKLIFT.GREY.PKG.KIT This part replaces 532414580. Price: $17.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 239 |
532110452 |
NUT PUSH M Price: $2.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
