| Ref | Part Number | Description |
|---|
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
530016153 |
Screw Price: $1.99 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 4 |
106-5363 |
SHAFT-ADJUSTER Price: $41.05 |
| 4 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
530015780 |
Screw Price: $1.99 |
| 6 |
114-9396 |
CAPSCREW-HH Price: $2.22 |
| 6 |
530095646 |
Assy-Fuel Pick-up Price: $2.99 |
| 7 |
530047442 |
Strap-Ground Price: $1.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
119-4164 |
WASHER-WAVE This part replaces 106-5335. Price: $2.73 |
| 8 |
530039198 |
Ignition Module Price: $29.99 |
| 9 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 9 |
530015814 |
Screw Price: $1.99 |
| 10 |
137-6132 |
SCREW-ADJUSTER, BEDBAR This part replaces 99-2096. Price: $32.54 |
| 10 |
530052296 |
Assy-Wire Harness Price: $4.99 |
| 11 |
530037793 |
Foam-Air Filter Price: $1.99 |
| 11 |
99-2098 |
WASHER Price: $7.01 |
| 12 |
119-4156 |
SPRING-COMPRESSION This part replaces 99-3755. Price: $0.91 |
| 12 |
530016101 |
Nut Price: $1.99 |
| 13 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 13 |
530057480 |
Assy-Air Box Price: $4.99 |
| 14 |
530035526 |
Grommet-Carb Adjust Price: Call Us |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
530054144 |
Seal-Carb Adapter Price: $2.99 |
| 16 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 16 |
530055698 |
Reflector-Heat Price: $1.99 |
| 17 |
137-6094 |
BEDKNIFE-EDGEMAX (RM 22IN) This part replaces 108-9095. Price: $166.88 |
| 17 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 18 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 19 |
530012550 |
Cylinder Price: $17.99 |
| 20 |
530049870 |
Backplate-Muffler Price: $3.99 |
| 21 |
530069608 |
Gasket-Muffler(kit) Price: $5.99 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
530037813 |
Diffuser-Muffler Price: $1.99 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 23 |
530036103 |
Screen-Spark Price: Call Us |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 24 |
530016132 |
Bolt-Muffler Price: $1.99 |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 25 |
545081885 |
Kit-Carburetor (Walbro-WT-89) This part replaces 530071820. Price: $22.99 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 26 |
530069608 |
Gasket-Carb. (kit) Price: $5.99 |
| 27 |
108-4269-01 |
WEIGHT Price: $146.07 |
| 27 |
530016386 |
Screw Price: $5.99 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 28 |
530049700 |
Carb. Adapter Price: $3.99 |
| 29 |
530016187 |
Screw Price: $1.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 30 |
530069608 |
Gasket- Adaptor(kit) Price: $5.99 |
| 31 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 32 |
137-8432 |
REEL+,7IN FWY(22)8 BLD This part replaces 108-9073. Price: $671.21 |
| 32 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 35 |
530031163 |
Bar Wrench Price: $4.99 |
| 36 |
530056363 |
Assy-Seal & Bearing Price: $11.99 |
| 37 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 38 |
545113101 |
CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
