| Ref | Part Number | Description |
|---|
| 0 |
640276 |
CARBURETOR Price: $77.00 |
| 1 |
603001306 |
BOLT FLG, M8X1.25X65 Price: $4.99 |
| 1 |
631615 |
SHAFT & LEV Price: $6.48 |
| 2 |
603001308 |
LOCK NUT, FLG M8 X 1.25 NYLON Price: $3.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 4 |
603001299 |
NUT-M6X1.0 FLNG ALL MTL LOCK Price: $1.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
603001055 |
BUSHING, GREASELESS Price: $5.99 |
| 6 |
640070 |
SHUTTER Price: $1.25 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 10 |
630973 |
SHAFT & LEV Price: $5.16 |
| 11 |
632045 |
SPRING Price: $1.25 |
| 14 |
603001154 |
PAD, GRIP TAPE, ACCELERATOR Price: $12.99 |
| 14 |
632790 |
SHUTTER Price: $1.37 |
| 16 |
603001305 |
NUT M6X1 MECH DEF CENTER Price: $2.99 |
| 16 |
631807 |
FUEL FITTING Price: $6.03 |
| 17 |
603003840 |
BOLT, SHOULDER, M8 X 70, HC Price: $11.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
640027 |
FUEL JET Price: $2.60 |
| 20A |
640053 |
CAP Price: $0.81 |
| 25 |
631867 |
FLOAT BOWL Price: $2.34 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
632816 |
FLOAT This part replaces 632765. Price: $5.90 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 35 |
36045A |
PRIMER Price: $4.99 |
| 36 |
632745 |
NOZZLE Price: $4.95 |
| 37 |
632547 |
O RING Price: $1.49 |
| 40 |
640032 |
NUT Price: $3.86 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
