| Ref | Part Number | Description |
|---|
| 1 |
631-04133A |
Clutch Lock, LH This part replaces 631-04133. Price: $13.42 |
| 2 |
631-04134B |
Clutch Lock, RH This part replaces 631-04134A. Price: $13.42 |
| 3 |
684-04105D |
HANDLE ASSEMBLY (LH) This part replaces 684-04105A. Price: $20.10 |
| 4 |
684-04106D |
HANDLE ASSEMBLY (RH) This part replaces 684-04106A. Price: $19.00 |
| 5 |
910-0224 |
HEX SCREW AB-TAP #10-16 x 0.500 This part replaces 710-0224. Price: $3.19 |
| 6 |
710-1026 |
Screw, 1/4-20, 1.750 Price: $5.94 |
| 7 |
710-1233 |
Screw, Machine, #10-24, 1.375 Price: $3.95 |
| 8 |
712-04064 |
Nut, Flange Lock, 1/4-20, Nylon Price: $3.64 |
| 9 |
720-0274 |
Grip, 1.0 ID x 5.0 Price: $9.99 |
| 10 |
720-04039 |
Knob, Shift Price: $9.09 |
| 11 |
931-05333B |
HANDLE PANEL This part replaces 731-05333. Price: $54.47 |
| 12 |
732-0193 |
Spring, .39 x .60 x .88 Price: $4.11 |
| 13 |
735-0199A |
Bumper, Rubber, .62 OD x .22 Price: $6.89 |
| 14 |
736-0262 |
Washer, Flat, .385 x .870 Price: $3.66 |
| 15 |
736-0463 |
Washer, Flat, .25 x .630 x .0515 Price: $3.91 |
| 16 |
738-04348 |
Screw, Shoulder, .437 x 1.345 x 1/4-20 This part replaces 738-04122. Price: $3.14 |
| 17 |
738-04125 |
Screw, Shoulder, .374 Dia. X 1.05 Price: $4.08 |
| 18 |
746-04227A |
Cable, Speed Selector This part replaces 746-04227. Price: $19.97 |
| 19 |
946-0605 |
Barrel Cable Hold Down This part replaces 746-0605. Price: $3.94 |
| 20 |
790-00140-0637 |
PANEL BRACKET Not Available This part replaces 790-00140. Price: |
| 21 |
790-00203-0637 |
SHIFT LEVER Not Available This part replaces 790-00203. Price: |
| 22 |
684-04104-0637 |
CHUTE CRANK ASSEMBLY This part replaces 684-04104. Price: $54.78 |
| 23 |
710-0572 |
Carriage Bolt 5/16-18 x 2.5" This part replaces 710-0449. Price: $3.75 |
| 24 |
710-1260A |
Screw, 5/16-18, 0.75, Gr5 Price: $3.34 |
| 25 |
714-0104 |
Pin, Cotter, .072 x 1.13 Price: $3.90 |
| 26 |
720-0201A |
Crank Knob, 1.0 Dia. x 3.2, Black Price: $9.62 |
| 27 |
720-0284 |
Knob Assembly, Wing Nut, 5/16-18 Price: $4.08 |
| 28 |
726-0100 |
Cap, Push, 3/8 Rod Price: $3.75 |
| 29 |
735-0234 |
Grommet, .44 ID x .94 OD .50 Price: $4.51 |
| 30 |
736-0185 |
Washer, Flat, .375 x .738 x .063 Price: $3.43 |
| 31 |
736-0451 |
Washer, Saddle, 320 x .93 x.060 Price: $3.75 |
| 32 |
747-04263 |
Eye Bolt, Chute Crank Price: $8.31 |
| 33 |
749-04138A |
Lower Handle This part replaces 749-04138. Price: $77.98 |
| 34 |
749-04141 |
Handle, Upper, RH Price: $47.01 |
| 35 |
749-04191A |
Upper Handle LH This part replaces 749-04142. Price: $34.63 |
| 36 |
731-04912B |
LOWER CHUTE 5" This part replaces 731-04912A. Price: $33.91 |
| 37 |
710-0276 |
Bolt, Carriage, 5/16-18, 1.0 Price: $3.68 |
| 38 |
712-04063 |
Nut, Flange Lock, 5/16-18, Nylon Price: $3.56 |
| 39 |
710-04071 |
Bolt, Carriage, 5/16-18, 1.0 Price: $3.94 |
| 40 |
710-0451 |
Bolt, Carriage, 5/16-18, .750 Price: $3.53 |
| 41 |
731-04426C |
UPPER CHUTE (W/LBL MANUAL TILT) This part replaces 731-04426A. Price: $17.04 |
| 42 |
736-0159 |
Washer.349 ID x .879 OD Price: $3.71 |
| 43 |
941-0475 |
BUSHING .380 ID This part replaces 741-0475. Price: $3.74 |
| 44 |
784-5647-0637 |
Chute Crank Bracket This part replaces 784-5647. Price: $12.51 |
| 45 |
731-04869A |
FLANGE KEEPER CHUTE This part replaces 731-04869. Price: $3.85 |
| 46 |
731-05319 |
Lens Price: $12.25 |
| 47 |
777X41805 |
Reflector Label, Lens Price: $8.16 |
| 48 |
710-04326 |
Screw, #8-16 x 0.50 Price: $3.37 |
| 49 |
710-04354 |
Screw, 1/4-20 x.375 Price: $3.38 |
| 50 |
753-04882C |
Pivot Rod This part replaces 711-04287. Price: $37.28 |
| 51 |
712-04081A |
Shoulder Nut, 1/4-20 Price: $6.49 |
| 52 |
731-04894D |
Plate, Lock This part replaces 731-04894A. Price: $4.61 |
| 53 |
731-04896C |
CLUTCH LOCK CAM This part replaces 731-04896A. Price: $3.56 |
| 54 |
732-04219C |
Clutch Lock Spring This part replaces 732-04219. Price: $3.70 |
| 55 |
732-04238B |
Torsion Spring, 0.8156 x .3038 This part replaces 732-04238. Price: $4.66 |
| 56 |
925-04213 |
Lamp This part replaces 725-04213. Price: $4.30 |
| 57 |
725-04214 |
HARNESS Not Available Price: |
