| Ref | Part Number | Description |
|---|
| 1 |
3272-21 |
PIN-COTTER Price: $3.09 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
30-8600 |
DISCONTINUED Price: Call Us |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 3 |
31-1340 |
DISCONTINUED Price: Call Us |
| 4 |
32-0300 |
DISCONTINUED Price: Call Us |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
36-4340 |
CLUTCH YOKE WA Price: $143.18 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
36-4370 |
DISCONTINUED Price: Call Us |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 7 |
32104-76 |
SCREW-HWHTF This part replaces 32104-63. Price: $2.29 |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 9 |
38-5460 |
DISCONTINUED Price: Call Us |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
31-1110 |
DISCONTINUED Price: Call Us |
| 11 |
27-3670 |
DISCONTINUED X-REF Price: Call Us |
| 11 |
545145802 |
ASSY CRANKSHAFT This part replaces 530012579. Price: $17.99 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 13 |
353-212 |
FITTING-ELBOW, 45 DEG Price: $22.12 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
36-7960 |
DISCONTINUED Price: Call Us |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
29-7530 |
DISCONTINUED Price: Call Us |
| 15 |
530016441 |
Screw Price: $1.99 |
| 16 |
115-4523 |
COUPLING-RUBBER This part replaces 27-6560. Price: $52.81 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
29-7540 |
DISCONTINUED Price: Call Us |
| 18 |
29-9980 |
DRIVE COUPLING WA Price: $238.68 |
| 18 |
530058709 |
Bulb - Purge Price: $4.99 |
| 19 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 19 |
545077501 |
Air Box Price: $7.99 |
| 20 |
322-7 |
SCREW-HH Price: $0.89 |
| 20 |
530016429 |
Screw Price: $1.99 |
| 21 |
29-7510 |
RUBBER COUPLING Price: $80.05 |
| 21 |
530036575 |
Foam-Air Filter Price: $1.99 |
| 22 |
323-8 |
SCREW-HH Price: $1.20 |
| 22 |
530057545 |
Cover-Air Box Price: $3.99 |
| 23 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 23 |
545081826 |
Kit - Ignition Module This part replaces 530039229. Price: $32.99 |
| 24 |
5-3638 |
DISCONTINUED Price: Call Us |
| 24 |
530059758 |
Spacer-Flywheel Price: $4.99 |
| 25 |
29-7520 |
DISCONTINUED Price: Call Us |
| 25 |
530016357 |
Screw Price: $1.99 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
530047278 |
Assy-Switch wire Price: $4.99 |
| 27 |
3245-7 |
SCREW-SET Price: $0.34 |
| 27 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 28 |
23-2300 |
FILTER-OIL, TRANSMISSION Price: $11.03 |
| 28 |
530054834 |
Handle-Starter Price: $1.99 |
| 29 |
353-678 |
DISCONTINUE Price: Call Us |
| 29 |
530071798 |
Kit - Rope Price: $3.99 |
| 30 |
530055122 |
Assy-Clutch Price: $8.99 |
| 31 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 31 |
530094189 |
Washer-Clutch Price: $2.99 |
| 32 |
323-39 |
SCREW-HH Price: $1.60 |
| 32 |
545016004 |
Assy.-Fan Hsg Price: $17.99 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 33 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 34 |
353-385 |
FITTING-STRAIGHT Price: $23.99 |
| 34 |
545050407 |
Kit-Starter Pulley Price: $11.99 |
| 35 |
33-4680 |
DISCONTINUED Price: Call Us |
| 35 |
545080601 |
Baffle Price: $6.99 |
| 36 |
27-3680 |
SPACER-MOUNTING Price: $6.65 |
| 36 |
530015880 |
Screw Price: $1.99 |
| 37 |
27-3690 |
GASKET-TRANSMISSION Price: $8.27 |
| 37 |
530016463 |
Washer-Clutch Flat Price: $1.99 |
| 38 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 38 |
530039243 |
Assy-Flywheel Price: $27.99 |
| 39 |
32-0040 |
DISCONTINUED Price: Call Us |
| 40 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 40 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 41 |
302-5 |
FITTING-GREASE This part replaces 21-6010. Price: $0.59 |
| 41 |
530055728 |
Outer Bearing Price: $6.99 |
| 42 |
31-8870 |
DRIVE SHAFT 22239 Price: $213.56 |
| 42 |
530019264 |
Seal-C'shaft Price: $2.99 |
| 43 |
32128-20 |
NUT-HF Price: $0.99 |
| 43 |
530032125 |
Inner Bearing Price: $11.99 |
| 44 |
33-4690 |
DISCONTINUED Price: Call Us |
| 45 |
251-288 |
BEARING-BALL Price: $85.99 |
| 45 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 46 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 46 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 47 |
31-8880 |
DISCONTINUED Price: Call Us |
| 48 |
530016386 |
Screw Price: $5.99 |
| 49 |
38-9170 |
DISCONTINUED Price: Call Us |
| 49 |
530057539 |
Shroud-Rear Price: $7.99 |
| 50 |
32151-83 |
RING-SNAP This part replaces 31-3150. Price: $0.34 |
| 50 |
530016445 |
Retainer-Tank Price: $1.99 |
| 51 |
31-2770 |
DISCONTINUED Price: Call Us |
| 52 |
30-1710 |
SCREW-SET Price: $3.32 |
| 52 |
530057973 |
Assy-Fuel Cap Price: $7.99 |
| 53 |
31-8890 |
DISCONTINUED Price: Call Us |
| 53 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 54 |
31-7230 |
DISCONTINUED This part replaces 30-9490. Price: Call Us |
| 54 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 55 |
31-5950 |
DISCONTINUED Price: Call Us |
| 55 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 56 |
31-5990 |
DISCONTINUED Price: Call Us |
| 57 |
530150247 |
Assy-Clutch Drum Price: $17.99 |
| 57 |
86-7220 |
GEAR-PINION This part replaces 23-4810. Price: $81.33 |
| 58 |
32120-72 |
RING-SNAP Price: $2.09 |
| 59 |
251-195 |
DISCONTINUED Price: Call Us |
| 59 |
530016319 |
Screw-Align Price: $1.99 |
| 60 |
530015772 |
Screw Price: $1.99 |
| 61 |
530016381 |
Screw 12-24 Price: $2.99 |
| 62 |
33-3250 |
DISCONTINUED Price: Call Us |
| 62 |
530016382 |
Nut 12-24 Price: $2.99 |
