| Ref | Part Number | Description |
|---|
| 1 |
82-8170 |
CLAMP Price: $17.27 |
| 1 |
966956201 |
KIT, HSG ASM 72 This part replaces 539131385. Price: $528.99 |
| 2 |
522478201 |
DECK SVC WH3615 W/DECALS Price: $1,499.99 |
| 2 |
93-7960 |
SPACER Price: $5.67 |
| 3 |
539100341 |
BLADE OEM 18" Price: $19.99 |
| 3 |
93-7961 |
CLAMP-DRAIN, CASE Price: $12.42 |
| 4 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 4 |
60-6700 |
BOLT-HH Price: $1.29 |
| 5 |
506113501 |
NUT FLANGE 1/2-13 GR 5 Price: $0.24 |
| 5 |
93-6687 |
DECAL-NO STEP This part replaces 36-3400. Price: $14.45 |
| 6 |
539132592 |
PLATE NUT - PAINTED Price: $22.99 |
| 6 |
93-9194 |
LIFT ARM WA - #5 *B Price: $897.89 |
| 7 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 7 |
539132583 |
HINGE CHUTE - BLACK Price: $30.99 |
| 8 |
237-21 |
O-RING Price: $0.70 |
| 8 |
539130903 |
CHUTE, RUBBER DISCHARGE WB Price: $49.99 |
| 9 |
539130922 |
BRKT, REINF-CHUTE WB Price: $34.99 |
| 9 |
75-5890 |
HOSE Price: $75.32 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 10 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 11 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 11 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 12 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 12 |
92-7564 |
HOSE-HYD Price: $84.98 |
| 13 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 13 |
98-8069 |
CYLINDER - HYD 1-5/8 This part replaces 93-7551. Price: $778.75 |
| 14 |
256-172 |
BUSHING Price: $4.57 |
| 14 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 15 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 15 |
94-1430 |
DISCONTINUED Price: Call Us |
| 16 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 16 |
93-4224 |
SHOCK ABSORBER Price: $143.44 |
| 17 |
596565401 |
Screws This part replaces 539990643. Price: $1.99 |
| 17 |
69-8980 |
WASHER Price: $0.58 |
| 18 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 18 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 19 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 19 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 20 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 20 |
98-8188 |
PIN WA W/NUT This part replaces 93-9189. Price: $9.33 |
| 21 |
539990254 |
WASHER 1/2" SPLIT LOCK Price: $2.99 |
| 21 |
88-0440 |
DISCONTINUED Price: Call Us |
| 21 |
93-6693 |
DECAL-PLATE, FLOOR Price: $10.84 |
| 22 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 22 |
99-5669 |
CARRIER FRAME WA This part replaces 93-2649. Price: $2,556.86 |
| 23 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 23 |
83-6780 |
PIN-CYLINDER Price: $130.51 |
| 24 |
328-7 |
SCREW-HH Price: $4.00 |
| 24 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 25 |
522000502 |
WEIGHT, COUNTER, ORANGE Price: $64.99 |
| 25 |
94-8949 |
BUSHING-FLANGE This part replaces 93-7408. Price: $2.51 |
| 26 |
539108374 |
HCS 1/2-13 X 1-1/2 GR 5 ZD Price: $2.99 |
| 27 |
94-1425 |
BAR - LIFT CENTER WA Price: $214.36 |
| 28 |
82-6490 |
HOSE Price: $83.18 |
| 29 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 30 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 31 |
75-5350 |
PIN-SLIDE, CYLINDER Price: $41.31 |
| 32 |
93-9193 |
DISCONTINUED Price: Call Us |
| 34 |
92-8754 |
DISCONTINUED Price: Call Us |
| 35 |
92-8002 |
SWITCH-LIFT, BACK BIASED Price: $105.67 |
| 36 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 37 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 38 |
138-6951 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2650. Price: $664.52 |
| 39 |
106-9208 |
SHORT CYLINDER PIN ASM This part replaces 83-6790. Price: $83.12 |
| 40 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 41 |
93-9190 |
DISCONTINUED Price: Call Us |
| 42 |
93-4234 |
SCREW-HSH Price: $6.08 |
| 44 |
93-9181 |
KNUCKLE - PIVOT *B Price: $573.32 |
| 45 |
94-8946 |
WASHER-THRUST This part replaces 94-1427. Price: $1.96 |
| 46 |
99-5610 |
PIN This part replaces 93-9161. Price: $40.16 |
| 47 |
93-7524 |
DISCONTINUED Price: Call Us |
| 48 |
94-8947 |
BUSHING-FLANGE This part replaces 93-7561. Price: $4.54 |
| 49 |
94-8948 |
BUSHING - STRAIGHT This part replaces 93-7409. Price: $7.56 |
| 50 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 51 |
92-7565 |
HOSE ASM Price: $89.51 |
| 52 |
92-7562 |
HOSE ASM Price: $71.47 |
| 53 |
2412-96 |
CLAMP-R Price: $3.46 |
| 54 |
322-4 |
SCREW-HH Price: $0.35 |
| 55 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 56 |
33104-060 |
SCREW-HHF Price: $1.02 |
| 57 |
53-6380 |
WASHER-FLAT Price: $8.62 |
| 58 |
33105-040 |
SCREW-HHF Price: $1.49 |
| 59 |
98-8811 |
CYLINDER - HYD This part replaces 93-7555. Price: $877.67 |
| 60 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
