| Ref | Part Number | Description |
|---|
| 1 |
3210-7 |
SCREW-HH Price: $0.61 |
| 2 |
3219-2 |
NUT-HEX Price: $0.37 |
| 3 |
322-17 |
SCREW-HH Price: $2.62 |
| 4 |
29-6162 |
SWITCH-MICRO Price: $107.13 |
| 5 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 6 |
46-8810 |
STOP-SPRING, LEAF Price: $9.17 |
| 7 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 8 |
3217-16 |
NUT-HEX Price: $0.25 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 10 |
29-6120-03 |
PUMP PLATE ASM This part replaces 29-6120. Price: $93.02 |
| 11 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 12 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 13 |
51-3150 |
SHIM-ARM, SPRING Price: $5.24 |
| 14 |
29-6170 |
EXTENDED LEAF SPRING ASM Price: $45.56 |
| 15 |
110-9650 |
LEAF SPRING ASM This part replaces 29-6150. Price: $33.06 |
| 16 |
321-6 |
SCREW-HH Price: $0.25 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
251-259 |
BEARING-BALL Price: $13.67 |
| 19 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 503283401 |
588171156 |
KIT CARB This part replaces 503283401. Price: $39.99 |
| 503478901 |
503478901 |
SPACER Price: $3.99 |
| 503479001 |
503479001 |
SCREW Price: $2.99 |
| 503479201 |
503479201 |
SCREW Price: $2.99 |
| 503479601 |
503479601 |
SCREW Price: $2.99 |
| 503479701 |
503479701 |
INLET NEEDLE Price: $8.99 |
| 503480001 |
537020801 |
PIN This part replaces 503480001. Price: $2.99 |
| 503480101 |
503480101 |
SCREW Price: $2.99 |
| 503480501 |
503480501 |
SCREW Price: $2.99 |
| 503480801 |
503994301 |
SPRING This part replaces 503480801. Price: $2.99 |
| 503481101 |
503481101 |
PLUG Price: $3.99 |
| 503481801 |
503481801 |
SCREW Price: $2.99 |
| 503481901 |
503481901 |
BUSHING Price: $5.99 |
| 503535701 |
503535701 |
STRAINER Price: $3.99 |
| 503665901 |
503665901 |
LEVER Price: $3.99 |
| 503755301 |
503755301 |
SCREW * Price: $2.99 |
| 503974001 |
503974001 |
WASHER Price: $2.99 |
| 503974301 |
503974301 |
COVER Price: $5.99 |
| 531004552 |
531004552 |
GASKET KIT (ZAMA GND39) Price: $9.99 |
| 531004553 |
531004553 |
CARBURETOR KIT (ZAMA RB69) Price: $17.99 |
| 537012501 |
537012501 |
BALL Price: $2.99 |
| 537012601 |
537012601 |
SPRING Price: $2.99 |
| 537019601 |
537019601 |
SHAFT Price: $6.99 |
| 537019701 |
537019701 |
SPRING THROTTLE Price: $2.99 |
| 537019801 |
537019801 |
LEVER Price: $3.99 |
| 537019901 |
537019901 |
THROTTLE FLAP Price: $3.99 |
| 537020001 |
537020001 |
PUMP DIAPHRAGM Price: $7.99 |
| 537020101 |
537020101 |
GASKET Price: $3.99 |
| 537020201 |
537020201 |
COVER Price: $19.99 |
| 537020301 |
537273401 |
SPRING This part replaces 537020301. Price: $4.99 |
| 537020401 |
537020401 |
GASKET Price: $3.99 |
| 537020601 |
537020601 |
NEEDLE HIGH SPEED Price: $3.99 |
| 537020701 |
537020701 |
SCREW Price: $6.99 |
| 537020801 |
537020801 |
PIN Price: $2.99 |
| 537020901 |
537020901 |
CHOKE SHAFT Price: $8.99 |
| 537021001 |
537021001 |
SPRING Price: $2.99 |
| 537021601 |
537021601 |
CAP Price: $2.99 |
| 537048901 |
537048901 |
DIAPHRAGM Price: $11.99 |
| 537049001 |
537049001 |
LEVER Price: $2.99 |
| 537127801 |
537127801 |
LOW SPEED NEEDLE Price: $14.99 |
