| Ref | Part Number | Description |
|---|
| 1 |
127-3071 |
WATER PUMP ASM Price: $827.54 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 3 |
125-6998 |
GASKET Price: $12.33 |
| 4 |
125-6999 |
PLATE Price: $58.91 |
| 9 |
127-3017 |
JOINT Price: $71.31 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
125-7123 |
PLUG Price: $9.86 |
| 11 |
127-3175 |
PLUG Price: $2.87 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 12 |
125-7195 |
PLUG Price: $2.71 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
125-7234 |
SCREW Price: $2.32 |
| 14 |
125-7047 |
GASKET Price: $5.13 |
| 15 |
125-6986 |
JOINT Price: $24.66 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
125-7048 |
O-RING Price: $2.87 |
| 17 |
125-6978 |
GASKET Price: $2.00 |
| 18 |
125-7192 |
GASKET Price: $1.14 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 19 |
93-0362 |
BOLT Price: $3.89 |
| 20 |
125-7214 |
BOLT Price: $3.77 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN.BK Price: $24.99 |
| 21 |
125-7219 |
BOLT Price: $4.58 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
125-7222 |
BOLT Price: $4.99 |
| 23 |
125-7039 |
V-PULLEY Price: $23.56 |
| 24 |
127-2998 |
V-BELT Price: $20.88 |
| 25 |
125-7206 |
BOLT Price: $1.97 |
| 26 |
125-7029 |
THERMOSTAT Price: $56.77 |
| 27 |
125-7026 |
GASKET Price: $2.90 |
| 28 |
125-7034 |
COVER Price: $78.09 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
125-7110 |
GASKET Price: $3.76 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
125-7594 |
BOLT Price: $3.00 |
| 31 |
125-6953 |
PLUG Price: $7.59 |
| 32 |
125-7124 |
SENSOR-THERMOSTAT, CW Price: $96.15 |
| 33 |
125-6979 |
GASKET Price: $2.55 |
| 34 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 35 |
127-3017 |
JOINT Price: $71.31 |
| 36 |
127-3072 |
WATER IN PIPE ASM Price: $51.67 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 40 |
127-3115 |
WATER OUT PIPE ASM Price: $21.26 |
| 41 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
127-3116 |
WATER OUT PIPE ASM Price: $47.67 |
| 44 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 47 |
127-3117 |
PIPE-OUT, CW Price: Call Us |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
581636201 |
BOLT.HEX.7/16-20X3.0XGR5 Price: $4.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
