| Ref | Part Number | Description |
|---|
| 1 |
86-5570 |
HOSE ASM Price: $151.86 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
86-3220 |
HOSE ASM Price: $68.45 |
| 3 |
237-22 |
O-RING Price: $2.43 |
| 4 |
340-138 |
FITTING-HYD, 45 DEG Price: $31.15 |
| 5 |
237-79 |
O-RING Price: $5.46 |
| 6 |
21-9260 |
COVER-DUST Price: $8.19 |
| 7 |
76-8140-03 |
BRACKET-GEAR, STEERING This part replaces 76-8140. Price: $70.53 |
| 8 |
76-8160-03 |
SUPPORT-GEAR, STEERING This part replaces 76-8160. Price: $25.24 |
| 9 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 9 |
532408667 |
KEEPER BELT ENGINE Price: $9.99 |
| 10 |
323-6 |
SCREW-HH Price: $0.66 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
74-3670 |
DISCONTINUED Price: Call Us |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 14 |
82-4950 |
PLUNGER-SPRING Price: $145.10 |
| 15 |
532422804 |
TANK FUEL Price: $149.99 |
| 15 |
74-5770 |
DISCONTINUED Price: Call Us |
| 16 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 17 |
74-5790 |
SHAFT-PIVOT Price: $75.26 |
| 18 |
32121-123 |
PIN-ROLL Price: $0.81 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 19 |
3220-3 |
NUT-HJ Price: $0.28 |
| 20 |
323-8 |
SCREW-HH Price: $1.20 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 21 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
76-9100 |
SPACER Price: $4.07 |
| 23 |
76-8720 |
PANEL - TOWER Price: $86.81 |
| 24 |
233-17 |
KNOB Price: $10.58 |
| 25 |
68-8080 |
WHEEL-STEERING Price: $273.84 |
| 26 |
72-0130 |
DISCONTINUED Price: Call Us |
| 27 |
107-2561 |
NUT-HEX This part replaces 47-6990. Price: $14.65 |
| 28 |
32144-4 |
SCREW-HWH Price: $1.29 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
76-9450 |
DISCONTINUED Price: Call Us |
| 30 |
84-0680 |
LINK-SHIFT V Price: $32.00 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 33 |
69-1560 |
DISCONTINUED Price: Call Us |
| 34 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 35 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 36 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 40 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 41 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
76-9050 |
ROD-BRAKE, PARK Price: $33.40 |
| 43 |
86-5730 |
RH FRONT TUBE ASM Price: $85.91 |
| 44 |
86-5740 |
LH FRONT TUBE ASM Price: $126.12 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 45 |
86-5720 |
DISCONTINUED Price: Call Us |
| 46 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 47 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 48 |
32144-57 |
SCREW Price: $1.04 |
| 49 |
2412-74 |
R-CLAMP Price: $2.37 |
| 50 |
340-159 |
FITTING-HYD, 90 DEG Price: $55.33 |
| 51 |
86-3210 |
DISCONTINUED Price: Call Us |
| 52 |
86-5470 |
DISCONTINUED Price: Call Us |
| 53 |
340-70 |
NUT-LOCK Price: $2.10 |
| 54 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 55 |
20-9500 |
WASHER Price: $3.53 |
| 56 |
31-0390 |
DISC-FRICTION Price: $11.25 |
| 57 |
76-8340 |
SHAFT-PIVOT, STEERING Price: $89.60 |
| 58 |
76-8150-03 |
SUPPORT-SHAFT, STEERING This part replaces 76-8150. Price: $25.87 |
| 59 |
74-3660 |
DISCONTINUED Price: Call Us |
| 60 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 61 |
59-6430 |
DISCONTINUED Price: Call Us |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 86 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
