| Ref | Part Number | Description |
|---|
| 1 |
137-6120 |
LONG REAR ROLLER ASM (3IN DIA)(27IN) This part replaces 112-8915. Price: $448.76 |
| 1 |
530015899 |
Screw Price: $1.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
530095646 |
Assy-Fuel Pickup This part replaces 530014362. Price: $2.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
530019172 |
Carburetor Gasket Price: $1.99 |
| 4 |
530069247 |
Fuel Line Price: $3.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
545057701 |
Filter-Air This part replaces 530036141. Price: $2.99 |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
530015970 |
Screw Price: $1.99 |
| 7 |
117-0960 |
PLASTIC WIEHLE ROLLER ASM Price: $482.64 |
| 7 |
530059738 |
Filter-Air This part replaces 530037478. Price: $7.99 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
530071987 |
CARBURETOR W-29 This part replaces 530035330. Price: $29.99 |
| 9 |
322-16 |
SCREW-HH Price: $3.39 |
| 9 |
530071654 |
Kit-Carb.-Adapter This part replaces 530037668. Price: $17.99 |
| 10 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 10 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 10 |
530037464 |
Carb. Grommet This part replaces 530037530. Price: $1.99 |
| 11 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 11 |
530015814 |
Screw-Line Limiter This part replaces 530015905. Price: $1.99 |
| 12 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 12 |
530053396 |
Carb. Adaptor This part replaces 530037667. Price: $2.99 |
| 13 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 13 |
545199901 |
IGNITION MODULE This part replaces 530039143. Price: $22.99 |
| 14 |
107-4026 |
SCREW-HH Price: $5.28 |
| 14 |
530019203 |
Turbo Clean Seal Price: $1.99 |
| 15 |
530029813 |
Turbo Air Cleaner Ass'y. Price: $1.99 |
| 15 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 16 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 17 |
530016154 |
Screw Price: $0.99 |
| 18 |
530069716 |
Cylinder Shield Price: $6.56 |
| 19 |
530037652 |
Heat Insulator Price: $1.99 |
| 20 |
530037872 |
Carburetor Plate Price: $1.99 |
| 22 |
530015895 |
Screw Price: $1.99 |
| 23 |
530037467 |
Switch Wire Ass'y. Price: $19.99 |
| 24 |
530015897 |
Screw Price: $1.99 |
| 25 |
530016170 |
Muffler Bolt Price: $1.99 |
| 26 |
530037249 |
Muffler Cover Price: $3.99 |
| 27 |
530036103 |
Spark Screen Price: Call Us |
| 28 |
530049031 |
Diffuser Price: $3.33 |
| 29 |
530015902 |
Bolt Price: $1.99 |
| 30 |
530037728 |
Muffler Body Price: $5.99 |
| 31 |
530047732 |
Piston Ring Price: $3.99 |
| 32 |
530015697 |
Piston Pin Retainer Price: $1.99 |
| 33 |
530069717 |
C'case&Cylinder Assy Price: $19.99 |
| 34 |
503920801 |
ASSY-CRANKSHAFT & ROD This part replaces 530029794. Price: $129.99 |
| 35 |
530032117 |
Piston Pin Bearing Price: $4.99 |
| 37 |
530019170 |
C'shaft Seal Price: $1.99 |
| 38 |
530032118 |
C'shaft Bearing Price: Call Us |
| 39 |
530019205 |
Muffler Gasket Price: $1.99 |
| 40 |
530056256 |
BACKPLATE MUFFLER This part replaces 530047801. Price: $8.99 |
