| Ref | Part Number | Description |
|---|
| 1 |
123418 |
Screw, Hx Hd, 1/2-20 x 1/2 In. Price: Call Us |
| 1 |
70-8050-03 |
BUMPER ASM This part replaces 70-8050. Price: $239.62 |
| 2 |
306570 |
Hubcap, 8 In. Price: Call Us |
| 2 |
59-5350-01 |
REAR DEFLECTOR WA This part replaces 43-1060. Price: $220.99 |
| 3 |
306669 |
Clip, Hubcap Price: Call Us |
| 3 |
322-4 |
SCREW-HH Price: $0.35 |
| 4 |
12467 |
Wheel Price: Call Us |
| 4 |
24167 |
Valve Stem Price: Call Us |
| 4 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 4 |
58276 |
Tire Price: Call Us |
| 5 |
315480 |
Hub Assembly Price: Call Us |
| 5 |
322-3 |
SCREW-HH Price: $0.79 |
| 6 |
12290 |
U-Joint Assembly Price: Call Us |
| 6 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 7 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
36311 |
Pin, Grooved, 1/4 x 1-1/2 In. Price: Call Us |
| 8 |
12465 |
Bracket, Steering Pivot, Outer Price: Call Us |
| 8 |
59-4920-01 |
IDLER WA This part replaces 59-4920. Price: $214.99 |
| 9 |
12325 |
Bearing Price: Call Us |
| 9 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 10 |
456722 |
Pin, Spring, 1/4 x 1-1/2 In. Price: Call Us |
| 10 |
59-4930-01 |
IDLER SLIDE This part replaces 59-4930. Price: $69.99 |
| 11 |
21682 |
Washer, Flat Price: Call Us |
| 11 |
59-4940-01 |
IDLER ROD WA This part replaces 59-4940. Price: $114.44 |
| 12 |
12288 |
Bushing, Shouldered Price: Call Us |
| 12 |
3290-211 |
WASHER-SPRING Price: $4.89 |
| 13 |
12321 |
Bushing, Shouldered Price: Call Us |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 14 |
12289 |
Pin, Steering Hinge Price: Call Us |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
12485 |
Bracket, Steering Pivot, Inner Price: Call Us |
| 15 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 16 |
122017 |
Screw, Hx Hd, 5/16-18 x 1 In. Price: Call Us |
| 16 |
56-4900-01 |
IDLER LEVER This part replaces 56-4900. Price: $25.99 |
| 17 |
120393 |
Washer, Flat, 11/32 In. Price: Call Us |
| 17 |
23-1120 |
WASHER Price: $16.99 |
| 18 |
1498 |
Nut, Hx, Ctrlk 5/16-18 Thd. Price: Call Us |
| 18 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 19 |
306001 |
Bracket, Transaxle Mounting Price: Call Us |
| 19 |
59-5170-03 |
PULLEY ASM This part replaces 59-5170. Price: $456.93 |
| 20 |
180089 |
Screw, Hx Hd, 5/16-18 x 2-1/4 In. Price: Call Us |
| 20 |
59-5190 |
NUT-PULLEY Price: $126.34 |
| 21 |
127-1843 |
PLUG-DOME This part replaces 59-5310. Price: Call Us |
| 21 |
304123 |
Spacer Price: Call Us |
| 22 |
306218 |
Arm, Rear Wheel Steer, L. H. Price: Call Us |
| 22 |
59-5270 |
V-BELT Price: $34.41 |
| 23 |
3290-211 |
WASHER-SPRING Price: $4.89 |
| 23 |
39728 |
Screw, Self-Tap, 3/8-16 x 3/4 In. Price: Call Us |
| 24 |
308446 |
Tie Rod, L.H. Price: Call Us |
| 24 |
59-5290-01 |
LATCH This part replaces 59-5290. Price: $25.44 |
| 25 |
308384 |
Tie Rod End, L.H. Price: Call Us |
| 25 |
77-0180 |
RH COVER ASM Price: $319.94 |
| 26 |
321-4 |
SCREW-HH Price: $0.99 |
| 26 |
412349 |
Nut, Hex, Ctrlk, 3/8-24 Thd. Price: Call Us |
| 27 |
124925 |
Nut, Hex, Jam, 3/8-24 Thd. Price: Call Us |
| 27 |
77-0160-01 |
SPRING BRKT WA This part replaces 77-0160. Price: $60.76 |
| 28 |
304260 |
Rod End Price: Call Us |
| 28 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 29 |
249-21 |
CLAMP-SLOTTED Price: $18.93 |
| 29 |
308447 |
Tie Rod End, R.H. Price: Call Us |
| 30 |
306217 |
Arm, Rear Wheel Steer, R.H. Price: Call Us |
| 30 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 31 |
181646 |
Screw, Hx Hd, 3/8-24 x 1-3/4 In. Price: Call Us |
| 31 |
32153-4 |
NUT-HEX, SIDE DEFORM Price: $0.75 |
| 32 |
56-4810-03 |
PULLEY ASM This part replaces 56-4810. Price: $229.99 |
| 32 |
~TRANSAXLE |
Contact nearest dealer Price: Call Us |
| 33 |
32121-8 |
PIN-ROLL, SLOTTED Price: $0.88 |
| 33 |
44108 |
Nut, Hx, Wd Fl, Lk 5/16-18 Thd. Price: Call Us |
| 34 |
304115 |
Spacer Price: Call Us |
| 34 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 35 |
25177 |
Washer, Flat, 49/64 In. Price: Call Us |
| 35 |
43-1120 |
WARNING DECAL Price: $7.84 |
| 36 |
308719 |
Steering Pivot Price: Call Us |
| 36 |
56-4920 |
PULLEY-IDLER Price: $85.99 |
| 37 |
181639 |
Screw, Hx Hd, 3/8-24 x 1-1/4 In. Price: Call Us |
| 37 |
323-6 |
SCREW-HH Price: $0.66 |
| 38 |
308720 |
Shaft, Steering Pivot Price: Call Us |
| 38 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 39 |
323-7 |
SCREW-HH Price: $0.65 |
| 39 |
421051 |
Screw, 5/16-24 x 1 In. Price: Call Us |
| 40 |
12319 |
Bolt, Shoulder, 3/8-24 Thd. Price: Call Us |
| 40 |
322-2 |
SCREW-HH Price: $0.69 |
| 41 |
302593 |
Rod Assembly, Rear Wheel Steer Price: Call Us |
| 41 |
44-7770-01 |
REAR SHELF WA This part replaces 44-7770. Price: $405.61 |
| 42 |
446363 |
Washer, Flat, 3/8 In. Price: Call Us |
| 42 |
92-6297-01 |
FRONT DEFLECTOR WA This part replaces 67-7540. Price: $124.99 |
| 43 |
304127 |
Bracket, Transaxle Stabilizer Price: Call Us |
| 43 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 44 |
35498 |
Screw, Hx Hd, Self-Tap, 5/16-18 x 3/4 In. Price: Call Us |
| 44 |
44-7780-01 |
RH SHELF This part replaces 44-7780. Price: $28.73 |
| 45 |
180075 |
Screw, Hx Hd, 5/16-18 x 5/8 In. Price: Call Us |
| 45 |
77-0130-01 |
PULLEY COVER WA This part replaces 77-0130. Price: $156.68 |
| 46 |
3256-12 |
WASHER-FLAT This part replaces 3256-13. Price: $0.99 |
| 46 |
451814 |
Screw, Hx Hd, Self-Tap, 5/16-18 x 5/8 In. Price: Call Us |
| 47 |
302877 |
Assembly, Sector Gear Price: Call Us |
| 47 |
3290-55 |
RIVET-POP Price: $0.25 |
| 48 |
302878 |
Bushing, Sector Gear Price: Call Us |
| 48 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 49 |
304296 |
Screw, Hx Hd, 1/2-20 x 2-3/8 In. Price: Call Us |
| 49 |
325-32 |
SCREW-HH Price: $5.77 |
| 50 |
274654 |
Nut, Hx, Ctrlk, 1/2-20 Thd. Price: Call Us |
| 51 |
308341 |
Plate, 4-Wheel Steer Pivot Price: Call Us |
| 52 |
308399 |
Nut, Jam, 3/8-24 Thd. Price: Call Us |
| 53 |
304116 |
Cam Yoke Roller Price: Call Us |
| 54 |
302594 |
Arm, Roller Swing Price: Call Us |
| 55 |
304122 |
Shoulder Bolt, Cam Roller Price: Call Us |
| 56 |
302588 |
Shoulder Bolt, Cam Follower Arm Pivot Price: Call Us |
| 57 |
35410 |
Spring, Clutch/Brake Pedal Return Price: Call Us |
| 58 |
120382 |
Washer, Split Lock Price: Call Us |
| 59 |
45602 |
Washer, Flat Price: Call Us |
| 60 |
3021 |
Woodruff Key, #606 Price: Call Us |
