| Ref | Part Number | Description |
|---|
| 1 |
420495X431 |
AUGER 27 LH Price: Call Us |
| 10 |
98-9614 |
CYLINDER HEAD COVER ASM Price: $256.63 |
| 20 |
98-9615 |
GASKET-COVER, HEAD Price: $20.34 |
| 30 |
98-9492 |
JOINT-PIPE, BREATHER Price: $9.68 |
| 40 |
98-9488 |
PLATE-ELEMENT, BREATHER Price: $1.33 |
| 50 |
98-9489 |
PLATE-ELEMENT, BREATHER Price: $7.89 |
| 52 |
751P12111A |
PISTON RING SET This part replaces 951-12111. Price: $5.82 |
| 53 |
951-11632 |
PISTON PIN SNAP RING Price: $3.53 |
| 54 |
951-12007 |
Piston Price: $31.34 |
| 55 |
951-11633 |
PISTON PIN Price: $6.66 |
| 56 |
710-04915 |
Bolt M6×12 Price: $3.82 |
| 57 |
951-11113 |
Air Shield Price: $8.11 |
| 58 |
751P11573A |
CONNECTING ROD This part replaces 951-11573. Price: $8.87 |
| 59 |
951-14053 |
Governor Shaft This part replaces 951-11356. Price: $13.94 |
| 60 |
736-04461 |
Washer 5.2×1.9 Price: $3.50 |
| 60 |
98-9493 |
ELEMENT-BREATHER Price: $6.10 |
| 61 |
951-11902A |
OIL SEAL This part replaces 951-11574. Price: $3.36 |
| 62 |
714-04078 |
Cotter Pin This part replaces 714-04074. Price: $3.66 |
| 63 |
951-11575 |
CAMSHAFT ASSEMBLY Price: $57.92 |
| 64 |
951-11369 |
Radial Ball Bearing, 6205 Price: $30.42 |
| 65 |
951-12160 |
Crankshaft Assembly Price: $121.65 |
| 66 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 67 |
751P11576A |
GOVERNOR GEAR This part replaces 951-11576. Price: $3.00 |
| 68 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04092. Price: $3.66 |
| 69 |
715-04089 |
DOWEL PIN Not Available Price: |
| 70 |
751P11371B |
CRANKCASE GASKET This part replaces 951-11371. Price: $3.07 |
| 70 |
98-9490 |
SHIELD-OIL, BREATHER Price: $1.28 |
| 71 |
751P17706 |
CRANKCASE COVER This part replaces 951-12125. Price: $29.04 |
| 72 |
710-04932 |
Bolt M8×32 Price: $3.66 |
| 73 |
951-11283 |
Oil Plug Price: $6.11 |
| 74 |
951-11578 |
OIL SEAL 25 x 41.25 x 6 Price: $13.04 |
| 76 |
951-12514A |
Oil Drain Plug This part replaces 951-12514. Price: $5.48 |
| 77 |
951-12126 |
Oil Seal 25×41.25×6 Price: $12.42 |
| 80 |
98-9364 |
SCREW (WITH WASHER) Price: $0.32 |
| 90 |
98-9455 |
NUT-CAP Price: $4.77 |
| 100 |
98-9454 |
GASKET Price: $1.43 |
| 110 |
107-9075 |
PLUG-FILLER, OIL Price: $7.25 |
| 120 |
99-3446 |
O-RING Price: $7.11 |
| 130 |
99-8349 |
EXTENSION-FILL, OIL Price: $107.00 |
