| Ref | Part Number | Description |
|---|
| 1 |
69649 |
ENGINE-Tecumseh HM-80 Price: Call Us |
| 2 |
72097 |
CRADLE Price: Call Us |
| 3 |
24910 |
SCREW (Taptite)-5/16"-18 x 1/2" Price: Call Us |
| 5 |
67430J |
PLATE-Serial Price: Call Us |
| 6 |
797483 |
SCREW This part replaces 36917. Price: $3.66 |
| 7 |
23594 |
MOUNT, Vibration Price: Call Us |
| 8 |
22129GS |
WASHER, Lock This part replaces 22129. Price: $2.61 |
| 9 |
39283 |
SCREW, Pan Head Machine-M8-1.25 x 20mm Price: Call Us |
| 10 |
59637 |
SCREW (Taptite)-3/8"-16 x 3/4" Price: Call Us |
| 11 |
36261 |
RIVET-Stainless Steel Price: Call Us |
| 12 |
70422GS |
ASSY, STATOR, S4002 This part replaces 70422. Price: $754.95 |
| 13 |
66365DGS |
ADPTR, HSNG, 8 HP This part replaces 66365D. Price: $56.99 |
| 14 |
66389 |
FAN, Cooling Price: Call Us |
| 15 |
72067 |
ROTOR Price: Call Us |
| 16 |
65791GS |
BEARING This part replaces 65791. Price: $32.00 |
| 17 |
46958 |
BOLT, Rotor-5/16"-24 x 8" Price: Call Us |
| 18 |
66825 |
CARRIER, Flear Bearing Price: Call Us |
| 19 |
66850GS |
ASSY, RECTIFIER, BRIDGE This part replaces 66850. Price: Call Us |
| 20 |
5022097SM |
CAP This part replaces 22097. Price: $2.75 |
| 21 |
66449F |
BOLT, Stator-M6-1.00 x 140mm Price: Call Us |
| 22 |
22264 |
WASHER, Lock-M6 Price: $8.99 |
| 23 |
66649 |
SCREW (Taptite)-M5-0.80 x 15mm Price: Call Us |
| 24 |
7072284YP |
SHAFT, Hex (3/8-24 thread, one end) This part replaces 72284. Price: $22.46 |
| 25 |
69759 |
RECEPTACLE-120 volts a-c Price: Call Us |
| 26 |
66819 |
BREAKER, Circuit-20 amp Price: Call Us |
| 27 |
7058295YP |
WELD UPPER SHIFTER This part replaces 72290. Price: $41.49 |
| 28 |
66386GS |
ASSEMBLY, BRUSH HOLDER This part replaces 66386. Price: $21.52 |
| 29 |
67451 |
FLAT WASHER-(SPECIAL) Price: Call Us |
| 30 |
5023365YP |
TIRE ASSM, 24X12.00-1 This part replaces 23365. Price: $415.73 |
| 31 |
22471GS |
NUT, #8-32 This part replaces 22471. Price: $2.39 |
| 33 |
25433 |
LUG, GROUNDING Price: Call Us |
| 34 |
67210AGS |
DECAL, GRD LUG This part replaces 67210A. Price: Call Us |
| 35 |
56893GS |
CRIMPTITE, 10-24 x 1/2 This part replaces 56893. Price: $1.95 |
| 36 |
22336 |
SCREW, Hex Head-5/16"-24 x 3/4" Price: Call Us |
| 37 |
67022GS |
GROMMET, RUBBER This part replaces 67022. Price: $2.55 |
| 38 |
7072296YP |
BAFFLE LH This part replaces 72296. Price: $28.99 |
| 39 |
7072280YP |
BRKT, TRACTION CABLE This part replaces 72280. Price: $19.36 |
| 40 |
705932 |
OUTLET-120V TL30A This part replaces 68868. Price: $34.97 |
| 41 |
68867GS |
OUTLET, 120/240V Locking, 20A This part replaces 68867. Price: $43.09 |
| 42 |
33528 |
SCREW, Pan Head-No. 10.32 x 1/4" Price: $47.62 |
| 43 |
73540 |
SCREW, Pan Head-M5-0.80 x 1" Price: Call Us |
| 44 |
84010414 |
VALVE, FUEL SHUT OFF This part replaces 22152. Price: $30.31 |
