| Ref | Part Number | Description |
|---|
| 1 |
140081 |
SUB= 144393 Price: Call Us |
| 1 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 2 |
69-9210-03 |
LEVER-LATCH, BRAKE Price: $15.85 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 3 |
138017 |
BRKT ASM SWAY BAR Price: Call Us |
| 3 |
321-4 |
SCREW-HH Price: $0.99 |
| 4 |
138440 |
BRKT DECK SW BAR Price: Call Us |
| 4 |
321-2 |
SCREW-HH Price: $2.79 |
| 4A |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 5 |
69-7790-03 |
PIN ASM Price: $31.86 |
| 6 |
130832 |
SUB= 130833 Price: Call Us |
| 6 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 7 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 7 |
73800500 |
NUT Price: Call Us |
| 8 |
106-0485-03 |
MOUNT-PEDAL, BRAKE Price: $126.17 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
3296-9 |
NUT-HEX Price: $0.25 |
| 11 |
99-3410 |
SWITCH Price: $95.63 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
3249-11 |
SCREW-MACHINE Price: $0.54 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 14 |
69-7880-03 |
LH BRAKE ARM ASM Price: $127.42 |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 16 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 16 |
69-5670 |
CABLE-BRAKE Price: $133.04 |
| 17 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 17 |
72110610 |
BOLT RDHD 3/8-16 Price: Call Us |
| 18 |
72140505 |
BOLT Price: Call Us |
| 19 |
69-7720-03 |
BRAKE PAWL ASM Price: $53.60 |
| 19 |
73800500 |
NUT Price: Call Us |
| 20 |
136888 |
SUB= 918136888 Price: Call Us |
| 20 |
69-7890-03 |
RH BRAKE ARM ASM Price: $127.42 |
| 21 |
69-7700-03 |
PEDAL ASM Price: $51.40 |
| 21 |
73800500 |
NUT Price: Call Us |
| 22 |
134753 |
STIFFENER BRKT Price: Call Us |
| 22 |
322-4 |
SCREW-HH Price: $0.35 |
| 23 |
131267 |
DEFLECTOR BRKT Price: Call Us |
| 23 |
49-6171 |
PAD-BRAKE, LH Price: $26.16 |
| 24 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 24 |
49-6172 |
PAD-BRAKE, RH Price: $25.03 |
| 25 |
123713X |
SPRING TORSION Price: Call Us |
| 25 |
69-9200 |
PIN Price: $22.07 |
| 26 |
110452X |
NUT PUSH M Price: Call Us |
| 26 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 27 |
130968 |
DEFLECTOR.SHIELD Price: Call Us |
| 27 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 28 |
19111016 |
WASHER Price: Call Us |
| 28 |
3255-24 |
WASHER-LOCK / EXT Price: $0.25 |
| 29 |
131491 |
HINGE ROD Price: Call Us |
| 30 |
138776 |
SUB= 157722 Price: Call Us |
| 31 |
129963 |
WASHER Price: Call Us |
| 32 |
129861 |
SUB= 153535 Price: Call Us |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 34 |
72110614 |
BOLT Price: Call Us |
| 35 |
133835 |
XMAS TREE FASTNER Price: Call Us |
| 36 |
131494 |
FLAT IDLER PULLEY Price: Call Us |
| 37 |
19131316 |
WASHER Price: Call Us |
| 40 |
73800600 |
NUT Price: Call Us |
| 41 |
133551 |
PIVOT ROD Price: Call Us |
| 43 |
140083 |
ROD CLUTCH W/NIBS Price: Call Us |
| 44 |
140088 |
GUARD MAND LH BLK Price: Call Us |
| 45 |
4497H |
RETAINER M Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 48 |
133944 |
HARD SMALL WASHER Price: Call Us |
| 49 |
133940 |
SUB= 151785 Price: Call Us |
| 50 |
131340 |
SHOULDER BOLT Price: Call Us |
| 51 |
69180 |
LOCKNUT Price: Call Us |
| 52 |
139888 |
BOLT.SHLD.5/16-18 Price: Call Us |
| 53 |
131845 |
BRAKE PAD ARM ASM Price: Call Us |
| 54 |
133943 |
HARDENED WASHER Price: Call Us |
| 55 |
140084 |
SUB= 151785 Price: Call Us |
| 56 |
122052X |
SPACER RETAINER Price: Call Us |
| 57 |
140090 |
KEEPER BELT LH 42 Price: Call Us |
| 58 |
140086 |
SPRING TORSN BRAK Price: Call Us |
| 59 |
141043 |
GUARD IDLER TUV Price: Call Us |
| 67 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 68 |
140067 |
BELT-V MWR 82.625 Price: Call Us |
| 71 |
142427 |
ROD CLUTCH 38/42 Price: Call Us |
| 72 |
131870 |
RETURN SPRING Price: Call Us |
| 73 |
127847 |
CLUTCH ARM SECOND Price: Call Us |
| 74 |
121748X |
WASHER Price: Call Us |
| 75 |
12000029 |
RING Price: Call Us |
| 76 |
128903 |
SHOULDER BOLT Price: Call Us |
| 77 |
127845 |
SPRING KEEPER Price: Call Us |
| 78 |
140334 |
SUB= 154810 Price: Call Us |
| 79 |
127498 |
BUSHING Price: Call Us |
| 80 |
128759 |
SUB= 918128759 Price: Call Us |
| 81 |
73350600 |
NUT Price: Call Us |
| 82 |
142028 |
TRUNION ADJ Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
