| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
136-2167 |
TREAD-FLOOR, RH Price: $33.46 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532175131. Price: $59.99 |
| 3 |
136-2166 |
TREAD-FLOOR, LH Price: $33.46 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
136-2124 |
FOAM-FILL, LH Price: $29.96 |
| 5 |
136-2125 |
FOAM-FILL, RH Price: $5.97 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
136-2165 |
TREAD-FLOOR, EDGE Price: $3.58 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
136-2177-03 |
PLATE-STEP Price: $37.77 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
3231-1 |
SCREW-CARR Price: $0.99 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
130-5748-03 |
COVER-MOUNT Price: $49.94 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
127-9861 |
FOAM-CORNER Price: $8.72 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
121-8548 |
FOAM-SEAL, REAR Price: $16.49 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
136-2184 |
TREAD-FLOOR Price: $500.26 |
| 15 |
136-2123-03 |
PLATE-DECAL Price: $65.03 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
117-2754 |
DECAL-WARNING Price: $25.01 |
| 17 |
130-6048 |
DECAL-SERVICE Price: Call Us |
| 17 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180641. Price: $59.99 |
| 18 |
130-5733 |
DECAL-INSTRUCTION Price: Call Us |
| 19 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 20 |
3269-22 |
RIVET-POP Price: $0.61 |
| 21 |
114-0846 |
DECAL-INSTRUCTIONS, OPERATING Price: $58.52 |
| 23 |
133-5618 |
DECAL-ARRESTER, SPARK Price: $3.63 |
| 24 |
138-6367 |
WRENCH This part replaces 121-3874. Price: $9.93 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $4.99 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $29.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819182411 |
Washer 9/16 ID x 1 1/2 OD 11 Ga. Zin Price: $4.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $59.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $4.99 |
| 54 |
871130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 85 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
