| Ref | Part Number | Description |
|---|
| 1 |
121472X |
SUB= 150546 Price: Call Us |
| 1 |
93-2085-01 |
ROD ASM Price: $134.61 |
| 2 |
142033 |
AXLE ASM FRONT Price: Call Us |
| 2 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 3 |
145410 |
SUB= 145410X431 Price: Call Us |
| 3 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 4 |
145413 |
SUB= 145413X431 Price: Call Us |
| 4 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 5 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 5 |
6266H |
WASHER .T Price: Call Us |
| 6 |
121748X |
WASHER Price: Call Us |
| 6 |
33124-020 |
SCREW-CARR Price: $0.88 |
| 7 |
19272016 |
WASHER Price: Call Us |
| 8 |
12000029 |
RING Price: Call Us |
| 8 |
93-2142 |
DISCONTINUED Price: Call Us |
| 9 |
105-9750-01 |
PLATE-FLOOR This part replaces 94-6399-01. Price: $194.85 |
| 9 |
3366R |
COL. SRTG. BEAR. Price: Call Us |
| 10 |
130468 |
SUB= 532130468 Price: Call Us |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
94-1371 |
SPACER Price: $14.81 |
| 12 |
73610600 |
SUB= 7810H Price: Call Us |
| 12 |
94-1383 |
PEDAL-PIVOT Price: $229.74 |
| 13 |
110438X |
BEARING Price: Call Us |
| 13 |
256-311 |
BUSHING-SPLIT Price: $13.37 |
| 14 |
33115-090 |
SCREW-HH Price: $13.76 |
| 14 |
74761060 |
BOLT LT Price: Call Us |
| 15 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 16 |
107-2550 |
CABLE-CONTROL, TRACTION This part replaces 93-2099. Price: $194.40 |
| 16 |
132624 |
AXLE PIN Price: Call Us |
| 17 |
128762 |
SUB= 156544 Price: Call Us |
| 17 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 18 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 18 |
57079 |
THRUST WASHER Price: Call Us |
| 19 |
124035X |
SUPPORT.SHAFT Price: Call Us |
| 19 |
94-1373 |
BRACKET-LOCK Price: $24.82 |
| 20 |
126684X |
SUB= 532126684 Price: Call Us |
| 20 |
94-1372 |
BRACKET-MOW Price: $18.44 |
| 21 |
10040400 |
LOCKWASHER Price: Call Us |
| 21 |
94-1375 |
TRUNNION-BRACKET, LOCK Price: $23.45 |
| 22 |
94-1374 |
TRUNNION-BRACKET, MOW Price: $14.18 |
| 23 |
127501 |
SUB= 918127501 Price: Call Us |
| 23 |
94-1386 |
SHAFT-PEDAL Price: $44.42 |
| 24 |
109816X |
NYLINER T Price: Call Us |
| 24 |
94-1304 |
CABLE-LOCK, NEUTRAL Price: $153.45 |
| 25 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
94-3489 |
SCREW-HH Price: $1.70 |
| 27 |
136874 |
GEAR SECTOR Price: Call Us |
| 27 |
140-6108 |
PIN-FLAG, NEUTRAL LOCK This part replaces 94-1300. Price: $31.21 |
| 28 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 29 |
17490612 |
SCREW Price: Call Us |
| 29 |
2411-34 |
JOINT-BALL Price: $29.99 |
| 30 |
3296-13 |
NUT-LOCK, NI Price: $0.34 |
| 31 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 32 |
130467 |
TIE ROD Price: Call Us |
| 32 |
33114-016 |
SCREW-HH Price: $0.27 |
| 33 |
19111216 |
WASHER M Price: Call Us |
| 33 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 34 |
10040500 |
LOCKWASHER Price: Call Us |
| 34 |
93-2279 |
CLAMP-CABLE Price: $7.12 |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 35 |
73810500 |
NUT.LOCK.5/16-24 Price: Call Us |
| 36 |
145207 |
BUSHING.STRG.3/4 Price: Call Us |
| 36 |
33115-016 |
SCREW-HH Price: $0.75 |
| 37 |
17541008 |
SCREW.10-24X1/2 Price: Call Us |
| 37 |
33014-00 |
NUT-HEX Price: $0.25 |
| 38 |
2411-38 |
JOINT-BALL Price: $21.96 |
| 39 |
100712K |
WASHER Price: Call Us |
| 40 |
73940800 |
SUB= 73360800 Price: Call Us |
| 41 |
100711L |
ADAPTER LT Price: Call Us |
| 43 |
121749X |
WASHER Price: Call Us |
| 46 |
121232X |
CAP Price: Call Us |
| 47 |
6855M |
ZERK M Price: Call Us |
| 56 |
19131210 |
WASHER Price: Call Us |
| 58 |
17490508 |
SCREW LT Price: Call Us |
| 59 |
105663X |
SUPPORT-SADDL T Price: Call Us |
| 60 |
105664X |
SUPPORT.SADDLE.FT Price: Call Us |
